Single Row 6pins Poe Rj45 Connector J0g 0059nl Right Angle With Led Finger - China

J0G-0059NL Single row 6pins PoE RJ45 Connector With LED With Finger J0G-0059NL DETAILS: 1 - RoHS CERTIFICATION 2 - PLASTIC HOUSING : THERMOPLASTIC MATERIAL WITH FLAMMABILITY RATING UL 94V-0 OR BETTER.

3 - CONTACTS PLATING: 50 MICROINCHES GOLD PLATING 4 - CONTACT BASE MATERIAL: PHOSPHOR BRONZE 5 - UNDER PLAATING : 30 - 50u INCHES NICKEL 6 - SOLDER TAIL PLATING: 150 - 300 MICROINCHES 100% TIN, MATTE FINISH 7 - METAL SHIELD: NICKEL PLATING ON COPPER ALLOY 8 - JACK CAVITY CONFORMS TO FCC RULES AND REGULATIONS PART 68 SUBPART F.

9 - PCB PLATING: EG 10 - STORAGE TEMPERATURE: - 20 TO +125 11 - COMPLIANCE TO J - STD: A.

J - STD -002: SOLDERABILITY AT 245 DIP AND LOOK TEST B.

J - STD -020: LEVEL 1, NO MOISTURE SENSITIVE C.

J - STD -075: W2, 270 MAXIMUM THROUGH WAVE SOLDER ELECTRICAL CHARACTERISTICS AT 25 UNLESS OTHERWISE SPECIFIED (FOR REDERENCE ONLY.

USED FOR CUSTOMER INFORMATION) - - - - PARAMETER | SPECIFICATION | OPERATING TEMP | 0 TO +70 | TURNS RATIO | 1 : 2% | POLARITY | PER SCHEMATIC | INSERTION LOSS | 100 KHz TO 125 MHz | -1.2 dB MAX | RETURN LOSS, 1000BT (Z OUT = 85, 100 AND 115 OHMS) | 1 -40 MHz | 40 - 100MHz | - 18dB MIN | -12+20*LOG10(f/80 MHz) dB MIN | INDUCTANCE (OCL) (MEDIA SIDE, 0 TO +70) | 350 uH MIN(MEASURED AT 100 KHz, 100 mVRMS AND WITH 8 mA DC BIAS) | CROSSTALK, ADJACENT CHANNELS | 1 - 100 MHz | -35 dB TYP | COMMON MODE REJECTION RATIO | 100 KHz TO 100 MHz | - 30 dB MIN | INPUT - OUTPUT ISOLATION | 2250 VDC MIN AT 60 SECONDS | - - - - PoE RJ45 Connector: - - - - EMMITTED COLOR | GREEN | ORANGE | YELLOW | WAVELENGTH(nM) | 565 | 607 | 588 | POWER DISSIPATION(Pd) | 105 mW MAX | 105 mW MAX | 100 mW MAX | DC FORWARD CURRENT | 25 mA MAX | 30 mA MAX | 30 mA MAX | FORWARD VOLTAGE(VF) @20mA | 2.2 V TYP | 2.0 V TYP | 2.1 V TYP | - - - - J0G-0059NL Single row 6pins PoE RJ45 Connector With LED With Finger PRODUCT PICTURE: J0G-0059NL Single row 6pins PoE RJ45 Connector With LED With Finger HOW TO ORDER 1 - Please send me your datasheet or part number you need.

2 - We will offer the replacement quotation for your reference 3 - The free samples are available for your approval.

4 - After sample testing, we will step into the mass order.

5 - The Proforma Invoice will send for your confirmation 6 - After the goods finished, we send the goods to you and tell you the tracking number.

7 - We will track your goods until you receive the goods.

Remarks: 1 - Sample orders are avaliable.

2 - Price is negotiable for orders of large quantity.

3 - Customized orders (OEM/ODM orders) are avaliable.

4 - Contact us for available flavors list.

International Certifications: 1 - ISO9001: 2008 2 - UL 3 - Reach 4 - RoHs Our service: 1 - 100% tested before shipping 2 - Have alternative for Halo, Pluse, Wurth, We-online, Chilisin, CoilcraftSame quality but better price 3 - Free sample available 4 - Provide new design for customer

Company Contact:

• Posted By: SHAREWAY TECHNOLOGY CO., LTD.

• Phone: 86-0755-32932627

• Address: C711 HUAQIAOXINCUN, MINZHI TOWN , LONGHUA NEW DISTRICT , 518131 , SHENZHEN ,CHINA, Shenzhen , guangdong , China

• Email:

• Website: https://www.smpsflybacktransformer.com

• Business Description: Established in 1998, we have around 500 staff at present.

  With the abundant productive capacity , we are able to delivery the goods within the short time.

  Moreover, we can provide the professional complete solution for PoE appliication.
