Switches Magnetic Ethernet Connector J0011d01nl 100 Base Tx Ce Certified - China

price: check with company for price

Switches Magnetic Ethernet Connector J0011d01nl 100 Base Tx Ce Certified

Products Photos Catalog Switches Magnetic Photos Catalog

J0011D01NL RJ45 Modular Jack Magnetic Power Connector For Switches.

Product Description: # 1x1 Tab-DOWN RJ45 Jack # 100 Base-TX 1x1 Tab-DOWN with LEDs 8-pin intergratedRJ45 magnetics # RJ45 magnetics connector (ICM), designed to support applications, such as SOHO (ADSL modems), LAN-on-Motherboard (LOM), Hub and Switches.

# Fast RJ45 Ethernet Features and Benefits: # RoHS peak wave solder temperature rating 260C # Suitable for CAT 5 & 6 Fast Ethernet Cable or better UTP Electrical Performance Summary: # Meets or exceeds IEEE 802.3 standard for 100Base-TX # 350 H minimum OCL with 8mA bias current # Minimum 1500Vrms isolation per IEEE 802.3 requiremen J0011D01NL RJ45 Modular Jack Magnetic Power Connector For Switches.

1x1 Tab-DOWN RJ45 Jack products: - - - - Electrical Specifications @ 25C - Operating Temperature 0C to +70C | RoHS Compliant Part Number (Number of Ports) | Turns Ratios | EMI Fingers | LEDs L/R | Insertion Loss (dB TYP) | Return Loss (dB TYP) 100 (15) | Return Loss (dB TYP) 100 (15) | Common Mode Rejection (dB TYP) | Hipot (Vrms) | TX | RX | 1-65 MHz | 1-10 MHz | 10-30 MHz | 30-60 MHz | 60-80 MHz | 1-30 MHz | 30-60 MHz | 60-100 MHz | 1-50 MHz | 50-150 MHz | @60Hz 1 MIN | J0006D01BNL | 1CT: 1 | 1CT: 1 | No | G/Y | -1.0 | -20 | -16 | -12 | -10 | -40 | -35 | -30 | -30 | -20 | 2250 | J0006D21NL | 1CT: 1 | 1CT: 1 | No | N/A | -1.0 | -20 | -16 | -12 | -10 | -40 | -35 | -30 | -30 | -20 | 2250 | J0006D21BNL | 1CT: 1 | 1CT: 1 | YES | G/Y | -1.0 | -20 | -16 | -12 | -10 | -40 | -35 | -30 | -30 | -20 | 2250 | J0011D01NL | 1CT: 1 | 1CT: 1 | YES | N/A | -1.0 | -20 | -16 | -12 | -10 | -40 | -35 | -30 | -30 | -20 | 2250 | J0011D01BNL | 1CT: 1 | 1CT: 1 | No | G/Y | -1.0 | -20 | -16 | -12 | -10 | -40 | -35 | -30 | -30 | -20 | 2250 | J0011D21NL | 1CT: 1 | 1CT: 1 | YES | N/A | -1.0 | -20 | -16 | -12 | -10 | -40 | -35 | -30 | -30 | -20 | 2250 | J0011D21BNL | 1CT: 1 | 1CT: 1 | YES | G/Y | -1.0 | -20 | -16 | -12 | -10 | -40 | -35 | -30 | -30 | -20 | 2250 | J0011D21ENL | 1CT: 1 | 1CT: 1 | YES | G/G | -1.0 | -20 | -16 | -12 | -10 | -40 | -35 | -30 | -30 | -20 | 2250 | J0012D21NL | 1CT: 1 | 1CT: 1 | YES | N/A | -1.0 | -20 | -16 | -12 | -10 | -40 | -35 | -30 | -30 | -20 | 2250 | J0018D21NL | 1: 1.41 | 1CT: 1 | YES | N/A | -1.0 | -20 | -16 | -12 | -10 | -40 | -35 | -30 | -30 | -20 | 2250 | J0018D21ENL | 1: 1.41 | 1CT: 1 | YES | G/G | -1.0 | -20 | -16 | -12 | -10 | -40 | -35 | -30 | -30 | -20 | 2250 | J0026D01NL | 1CT: 1 | 1CT: 1 | No | N/A | -1.0 | -20 | -16 | -12 | -10 | -40 | -35 | -30 | -30 | -20 | 2250 | J0026D01BNL | 1CT: 1 | 1CT: 1 | No | G/Y | -1.0 | -20 | -16 | -12 | -10 | -40 | -35 | -30 | -30 | -20 | 2250 | J0026D01ENL | 1CT: 1 | 1CT: 1 | No | G/G | -1.0 | -20 | -16 | -12 | -10 | -40 | -35 | -30 | -30 | -20 | 2250 | J0026D21NL | 1CT: 1 | 1CT: 1 | YES | N/A | -1.0 | -20 | -16 | -12 | -10 | -40 | -35 | -30 | -30 | -20 | 2250 | J0026D21BNL | 1CT: 1 | 1CT: 1 | YES | G/Y | -1.0 | -20 | -16 | -12 | -10 | -40 | -35 | -30 | -30 | -20 | 2250 | J0026D21ENL | 1CT: 1 | 1CT: 1 | YES | G/G | -1.0 | -20 | -16 | -12 | -10 | -40 | -35 | -30 | -30 | -20 | 2250 | J0026D21FNL | 1CT: 1 | 1CT: 1 | YES | G/Y | -1.0 | -20 | -16 | -12 | -10 | -40 | -35 | -30 | -30 | -20 | 2250 | J0026D21GNL | 1CT: 1 | 1CT: 1 | YES | YG/G | -1.0 | -20 | -16 | -12 | -10 | -40 | -35 | -30 | -30 | -20 | 2250 | J00-0014NL | 1CT: 1 | 1CT: 1 | No | N/A | -1.0 | -20 | -16 | -12 | -10 | -40 | -35 | -30 | -30 | -20 | 2250 | J00-0045NL | 1CT: 1 | 1CT: 1 | No | G/Y | -1.0 | -20 | -16 | -12 | -10 | -40 | -35 | -30 | -30 | -20 | 2250 | J00-0061NL | 1CT: 1 | 1CT: 1 | YES | N/A | -1.0 | -20 | -16 | -12 | -10 | -40 | -35 | -30 | -30 | -20 | 2250 | J00-0065NL | 1CT: 1 | 1CT: 1 | YES | G/Y | -1.0 | -20 | -16 | -12 | -10 | -40 | -35 | -30 | -30 | -20 | 2250 | - - - - J0011D01NL RJ45 Modular Jack Magnetic Power Connector For Switches.

J0011D01NL RJ45 Modular Jack Magnetic Power Connector For Switches.

HOW TO ORDER 1 - Please send me your datasheet or part number you need.

2 - We will offer the replacement quotation for your reference 3 - The free samples are available for your approval.

4 - After sample testing, we will step into the mass order.

5 - The Proforma Invoice will send for your confirmation 6 - After the goods finished, we send the goods to you and tell you the tracking number.

7 - We will track your goods until you receive the goods.

Remarks: 1 - Sample orders are avaliable.

2 - Price is negotiable for orders of large quantity.

3 - Customized orders (OEM/ODM orders) are avaliable.

4 - Contact us for available flavors list.

International Certifications: 1 - ISO9001: 2008 2 - UL 3 - Reach 4 - RoHs Our service: 1 - 100% tested before shipping 2 - Have alternative for Halo, Pluse, Wurth, We-online, Chilisin, CoilcraftSame quality but better price 3 - Free sample available 4 - Provide new design for customer


Company Contact:


  • Phone: 86-0755-32932627

  • Address: C711 HUAQIAOXINCUN, MINZHI TOWN , LONGHUA NEW DISTRICT , 518131 , SHENZHEN ,CHINA, Shenzhen , guangdong , China

  • Email: Email


Published date: January 8, 2018

  • Business Description: Established in 1998, we have around 500 staff at present.

    With the abundant productive capacity , we are able to delivery the goods within the short time.

    Moreover, we can provide the professional complete solution for PoE appliication.
