Wifi Monitoring Iot Gateway Device Automation With Rs232 Rs485 Series Port - China

WIFi IOT automation device, WiFi monitoring with IOT Gateway System Feature # Cortex M3 32-bit ARM # Double watchdog to ensure stability # Support signal fileter # Support automatic network reconnection and data re-send # Synchronize clock with multiple way, Sms, NTP, CwtIO Server # Automatically execute preset task by schedule(second, minute, day, week, month) # Can automatically execute tasks according to preset Events # Provide console utility for visual programming over 100 parameters # Optional inside battery that life is 8-20 hours, cellular module Intelligent sleep when power lost DI feature # Accept NO or NC dry contact DO(T) feature # Open-collector output(drive voltage=power supply voltage, Drive current500mA) # DO can be activated by remote or local schedule # Remember status when power lost DO(K) feature # Relay NO contact output(load: 2A / 125VAC, 220VDC) # Remote or local event activate DO on/off/pulse # Remember status when power lost AI feature # 4-20mA (option: 0-5V) in, Sampling frequency: 33Hz, 10-bit precision) # Convert 4-20mA(0-5V) to physical value # Support offset and gain, alarm parameters, upload data setting # Signal lost alarm SMS feature # Support 10 cell phone numbers for alarm and control # Any device alarm status can be sent by sending sms # Customizable sms messages, like alarm, receove, report # Query any IO channels status or value via sms command # Control output via sms command # Configurable schedule for sms report IO channel's status or value # Remote setting via sms commands # Can query SIM card balance, sms forward # Support power lost sms alarm and recover sms(works with inside battery) # Wireless network communication # Option network: cellular(2g/3g/4g) or Wi-Fi # Support TCP/IP two-way communication with Max.

4 servers(IP or domain) # Events(e.g. alarm, timer) trigger upload data # Support http post, Modbus TCP, CWT protocol over cellular or Wi-Fi # Support two-way data transparent transmission with RS485 or RS232 Modbus feature # polling salve over RS485 with modbus rtu protocol # Can be a I O module to be read/write by modbus master # As modbus to gprs/3g gateway TI feature # Can set high or lower level to alarm, data log via wireless network # Can switch or F # Support probe disconnect alarm
