Outdoor Led Billboard Display Screen High Resolution Waterproof P10 Steel Cabinet - China

Video wall outdoor led billboard display screen high resolution waterproof P10 steel cabinet 6500nits Feature: With 85-264VAC large scale switching power supply input, typical value: 110VAC/220VAC.

Pixel pitch is 0.39 inch (10mm) for outdoor usage; Popular DIP346 led type, 1 red 1 green and 1 blue, traditional dip type led; Cabinet resolution are W 96 x H 96 dots, cabinet size is W 37.8 x H 37.8 inch; More than 960Hz refreshing frequency and 14bit grey scale; 110 Horizontal viewing angle and 55 vertical viewing angle; Driving method is 1/4 can constant current; Physical density: 929dots per square feet (10000 dots per square meters); Module pixel configuration of W 32 H 16 dots; Module size is W 12.6 X H 6.3 inch (W 320 H 160 mm); Detailed Description: 1 - High brightness DIP346 Led lamps are adopted, so the led screen has high brightness of 7000nits and you can see clearly from a long distance even in direct sunlight; 2 - Static scanning technology and module design technology are adopted to offer higher reliability and stability; Popular Application: Commercial centers, railway stations and large-scale entertainment plazas; 1 - Fast maintanance 2 - Adopt grating air convection cooling system, good heat dissapation 3 - Strict waterproof gurantee of quality IP65 4 - Stablity quality and lifetime maintenance 5 - DIP346 led screen waterproof 6 - Anti-corrosion, UV resistant 7 - Available - texts, pics, video advertising contents 8 - Lamp board and driver board separate P10 outdoor fixed led display has DIP and SMD lamp, two soution.

Each has its own advantages.

P10 Outdoor LED Display - - - - ITEM | P10 | Pixel Pitch() | 10 | Pixel Density(pixel/) | 10000 | Pixel Component | 1R1G1B | LED Configuration | SMD3535 DIP346 | Panel Dimension(WH) | 320*160 | Scan Mode | 1/4 (or 1/2) | Cabinet Dimension(WH) | 960*960/Customized | Cabinet Material | Iron/Customized | Brightness(cd/) | 6000 ( or 7000) | Color Temperature | 3200K-9500K | Viewing Angle(V) | 140 | Viewing Angle(H) | 140 | Contrast Ratio | 3000: 1 | Max Power Consumption(w/) | 750 | Ave Power Consumption(w/) | 300 | Operating Power Source | AC85~264V(47-63Hz) | Frame Frequency(Frame/S) | 60 | Refresh Rate(Hz) | 1200 | Gray Level | RGB65536Grade | Brightness Adjustment Level | 256Grade | Brightness Adjustment Mode | Manual/Automatic/Programm able | Control Distance | UTP100mMuti Mode Fiber500mSingle Mode Fiber10Km | Operating Temp | 2050 | Operating Humidity | 10%90%RH | Protecting Rating | IP65 | MTBF | 10000h | LED Life Span | 100000h | LED Best View distance | m-300m | - - - - Pre-sale service: 1 - Reply enquiries in 16 hours.

2 - Market research and forecast for customer.

In-sale service: 1 - Tracking report in producing.

2 - Quality test report for every order.

3 - Photos and videos as per customer's requirement.

After-sale service: 1 - Lifetime free maintenance and upgrade.

2 - Complaint respond period not exceed 24 hours; maintenance guidance and problem solution supplied in 48 hours.
