    • Usb 1d Ccd Scanner Module 300 Times S Decoding Speed Barcode Reader Component - China

    price: check with company for price

    Usb 1d Ccd Scanner Module 300 Times S Decoding Speed Barcode Reader Component

    Products Photos Catalog Usb Ccd Scanner Module Photos Catalog

    USB 1D CCD Scanner Module, 300 Times /S Decoding Speed Barcode Reader Component - - - - Physical Parameter | | C | 6g | Dimension | (L)26.5mm * (W)20.0mm *(H)11.5mm | Interface Type | FFC 12PIN Pitch 0.5 | Communication Mode | USB(USB-KBW, USB-COM), TTL, PS2 | Power Supply | DC 3.3-5V@50mA(work) | Performance | | Scan Type | Linear CCD | Light Source | Visible red light, 62510nm | CPU | 32-bit | Resolution | 2500 | Resolution | 3mil/0.076mm(PCS90%, Code 39) | Decoding speed | 300times/s | Depth of field | 30mm-700mm | Scan Mode | Manual, Continuous, Auto sense, Flashing | Scan Angle | Roll30, Pitch60, Skew60(PCS90%, Code 39, 10mil/0.25mm) | Print Contrast Signal | 20% | Ambient Light | Dark environment, indoor natural light | Symbologies | UPC-A, UPC-E, EAN-8, EAN-13, ISSN, ISBN, Code 128, GS1-128, ISBT 128, Code 39, Code 93, Code 11, Interleaved 2 of 5, Matrix 2 of 5, Industrial 2 of 5, Standard 2 of 5(IATA), Codabar(NW-7), Plessey, MSI Plessey, RSS, China Post, etc.

    | Environmental | | Operating temperature | -20 to 50 | Storage temperature | -40 to 70 | Humidity | 5% to 95%(non-condensing) | Drop Height | 1.2 meters | Transport vibration Test | 10H@125RPM | Depth of field | | 3MIL | 80-120mm (PCS90%, Code 39) | 13MIL | 30-320mm (PCS90%, EAN-13) | 20MIL | 30-450mm (PCS90%, Code 39) | 40MIL | 130-700mm (PCS90%, Code 39) | Accessories List | | Cable(Optional) | USB Cable, used to connect the DE1400 to a host device.

    RS232 Cable, used to connect the DE1400 to a host device, with USB supply cable.

    PS2 Cable, used to connect the DE1400 to a host device and keyboard input device.

    | Development board(Optional) | Equipped with a trigger button, beeper and RS-232 & USB output function.

    | Power Adaptor | Output: DC5V 1A, Input: AC100~240V 50~60Hz(serial port optional).

    | - - - -


    Company Contact:


    • Phone: 86-755-21032537

    • Address: 3/F, Longsheng Times Building, Industrial Road, Longhua District, Shenzhen, 518000, China​​​​​​†‹, Shenzhen , Guangdong , China

    • Email: Email

    Published date: March 6, 2018

    • Business Description: All products pass CE, ROHS, FCC, ISO9001, ISO14001, Grade I National Standard for Laser Safty certification, etc.

      Widely used in industry, commerce, transportation, finance, medical and health, tobacco industry, mobile payment and office automation.
