Usb Handheld Barcode Scanner 300 Times S Decoding Speed 32 Bit Cpu Blue Lightds5201 - China

2500 RoHS RS232 1d micro usb barcode scanner Product Description DS5201 is a high-performance 1D barcode scanner with leading CCD image recognition technology.

It can easily read the paper, goods, screen and other media barcodes.

Widely used in manufacturing, warehouse, logistics, health care, retail chain, mobile payment, express delivery, inventory management, food traceability, asset inventory, etc.

Features Ergonomic Industrial design, comfortable using.

Read all mainstream 1D barcodes in the market easily.

High-performance processor, fast decoding.

(3mil) High definition Blue ray lighting, anti-glare.

Interface: USB.

Widely used in supermarket, inventory management.

Application Supermarket Warehouse Mobile payment Retail chain Courier Health care - - - - Physical Parameter | | Weight | 165g(without cable) | Dimension | L175mm * W72mm * H100mm | Interface Type | USB | Communication way | USB(USB-KBW, USB-COM) | Power supply | DC 5V@100mA(work) | Performance | | Scan type | Linear CCD | Light source | Visible red light, 62510nm | CPU | 32-bit | Resolution | 2500 | Resolution | 3mil/0.076mm(PCS90%, Code 39) | Decoding speed | 300 times/s | Depth of field | 10mm-600mm | Scan mode | Manual, Continuous, Auto sense | Scan angle | Roll30, Pitch60, Skew60(PCS90%, Code 39, 10mil/0.25mm) | Print contrast signal | 20% | Ambient light |, Dark, Indoor natural light | Symbologies | UPC-A, UPC-E, EAN-8, EAN-13, ISSN, ISBN, Code 128, GS1-128, ISBT 128, Code 39, Code 93, Interleaved 2 of 5, Matrix 2 of 5, ITF-6, ITF-14, Industrial 2 of 5, Standard 2 of 5(IATA), Codabar(NW-7), Plessey, MSI Plessey, RSS, etc.

| Environmental | | Operating temperature | -20 to 50 | Storage temperature | -40 to 70 | Humidity | 5% to 95%(non-condensing) | Drop Height | 1.8m | Transport vibration Test | 10H@125RPM | Depth of field | | 3MIL | 60-100mm (PCS90%, Code 39) | 13MIL | 10-320mm (PCS90%, EAN-13) | 20MIL | 10-430mm (PCS90%, Code 39) | 40MIL | 110-600mm (PCS90%, Code 39) | Accessories list | | Data cable | USB, connect the scanner to a host device | - - - -
