10mm Plate Thickness Pit Mounted Weighbridge Mechanical Truck Scale Large Screen Display - China

80 ton Pit Type Weighbridge Truck Scale With 3 Way Video Monitoring Scale Cap Size Selection Description: It would be best if users have the size requirements, Our company can customize any standard sizes of the weighbridge.

For customer who use for the truck that collecting food or recycle, it is recommended that customers use platform 6m or blew.

Normally agricultural vehicles wheelbase are below 5 meters .

If using with vehicle that have 4 front wheels and 8 back wheels, can recommend 10 or 9 meters weighbridge as these vehicle wheelbase are around 8.5m If users needs to use the scale for trailer or tractor it is recommended to install 16 m or 18 m and above weighbridge, tractor length are about 14.5 meters or 17.5 meters.

Printing requirements configuration instructions: Micro-printer, print out a small ticket.

Weighing Scale Display Screen Large-screen digital display, vehicle weighing instrument display indoor and outdoor large-screen display while weighing screen can be made into 3, 5, 7-inch three sizes.

(Single function) - - - - Model | Max weighing (T) | Scale body | division value (kg) | Sensor (T*pieces) | SCS-20 | 20 | 37(single) | 10 | 104 | SCS-30 | 30 | 37(single) | 10 | 204 | SCS-30D | 30 | 39(single) | 10 | 204 | SCS-30B | 30 | 312(single) | 10 | 204 | SCS-30C | 30 | 314(double) | 10 | 206 | SCS-40 | 40 | 312(single) | 10 | 204 | SCS-50 | 50 | 3.414(double) | 20 | 206 | SCS-50B | 50 | 314(double) | 20 | 204 | SCS-50C | 50 | 318(double) | 20 | 206 | SCS-60B | 60 | 3.416(double) | 20 | 206 | SCS-60C | 60 | 318 (double) | 20 | 206 | SCS-60D | 60 | 1)3.418(double); 2)3.418(three) | 20 | 206 | SCS-80 | 80 | 3.416(double) | 20 | 306 | SCS-80A | 80 | 1)3.418(double); 2)3.418(three) | 20 | 1)306; 2)308 | SCS-80B | 80 | 3.421(three) | 20 | 308 | SCS-100 | 100 | 3.416(double) | 50 | 306 | SCS-100A | 100 | 3.418(three) | 50 | 308 | SCS-100B | 100 | 3.421(three) | 50 | 308 | SCS-100C | 100 | 3.424(three) | 50 | 308 | - - - -

Company Contact:

• Posted By: Hebei Pinglei Weighing Apparatus Co., Ltd

• Phone: 86-137-39722345

• Address: 500 Meters By The Intersection Of Hengjing Road and Fangxi Road, Luancheng District, Shiajizhuang, Shiajizhuang , Hebei , China

• Email:

• Business Description: With the tenet of "People oriented, quality oriented, honest centered", our business policy is "Top quality, excellent service, good reputation".

  We look forward to cooperating with your company in the near future.
