High Brightness Advertising Outdoor LED Screens Full Color Video Billboard P5 Waterproof IP65 Module - - - - Technical Specifications | NO | Product name | outdoor P5 led display | 1 | Pixel Pitch(mm) | 5mm | 2 | Pixel configuration | 1R1G1B/ | 3 | Pixel density | 40000 dots/m2 | 4 | Brightness | 6500cd/m2 | 5 | Module size(W*H) | 320mm * 160mm | 6 | Module Resolution (W*H) | 64 dots x 32dots | 7 | Module weight | 500g | 8 | Cabinet size (W*H) | 640mm640mm | 9 | Drive IC | MBI5124 | 10 | Drive mode | 1/8scan | 11 | Viewing Angle(V/H) | 140C | 12 | Grey Scale | 65536 degree | 13 | Life time | >100, 000 Hours (50%) | 14 | MTBF | >50, 000 Hours | 15 | Operating Voltage | AC110V/220V10% | 17 | Screen Power Consumption | Max: 680w/m2; Average: 220w/m2 | 18 | Input Power Frequency | 50/60Hz | 19 | Operating temperature | -30--60C | 20 | Humidity | 10%-95% | 21 | Refresh Rate | 1200HZ | 22 | Control Method | Synchronized with computer monitor | 23 | Color Temperature | 6500K-9500K | 24 | LED control system | LINSN, Nova-star, Colorlight is selectable | 25 | Control Distance | 100 m (no repeating); Optical fiber transmission: 500m- 15km | 26 | Accepting signal with video processor | PAL/NTSC/SECAM, S-Video;VGA;RGB;Composite Video;SDI | 27 | Systems Operating Platform | Windows Xp / Windows 7 / windows 8 /8.1 / windows 10 | - - - - Product Introduction : 1 .

High brightness, big viewing angle with SMD3535 led lamp, brightness about more than 6500cd / m, perfectly suited for outdoor environment, 3 in 1 led lamp blending well, especially good color reproduction and viewing angle, giving the visual sense and feel much more than traditional outdoor DIP full color display.

2 .

The total amount of heat reduced.

Using energy-saving (low constant current from the control point), high efficiency constant current chip;Using high brightness and high efficiency of LED lamps; 3 .

The automated process.

All using SMD process, fully automated machine operation, reducing human error and damage and improves reliability.

4 .

Low failure rate.

Using sophisticated type of material, in terms of testing: instrument light intensity distribution, it is a direct measurement of the LED lamp light intensity, viewing angle, wavelength, and other optical properties; aging test LED lamps attenuation; an IC testing stand, strict control the quality of the IC.

High-temperature aging at the end of the production process and cabinet vibration test, good control of Weld and other issues.

5 .

Cabinet Select: Die casting Aluminum; Aluminum profile cabinet; Brushed aluminum cabinet; water proof cabinet .

Fast locks and assembling pins, flatness and seamless are greatly increased, less than 0.01mm, easy to install and dismantle .

Seamless connection, less than 0.1mm between 2 cabinet.

Feature: 1 - With good lightening accordance and no mosaic 2 .

Can play different formats of image files, flash, WAV/MIDI, video signal from TV, video signal from video and other equipment 3 .

Different video frequency can be changed freely at the same time, and the image can be enlarged and reduced 4 .

High brightness, and can be adjustable, meets the need of changing requirement of customer in environment 5 .

Usually use for advertising outdoor Application and Market : 1 - Application Widely use in stadiums, advertisement, banks, securities exchange, stations, shopping malls, postal offices, schools, restaurants, entertainment, enterprises, highway etc 2 - Market: North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, MID East, Eastern Asia, Western Europe Packaging & Shipping : 1 .

Packaging : Paper carton, Antishaking wooden box, flight cases or according to your request to ensure safety during transportation.

2 .

Shipping : 3-15 days after receiving your payment
