High Brightness Outdoor Led Advertising Display With 1 4 Scanning 7500cd Sqm - China

High Brightness Outdoor Led Advertising Display With 1 / 4 Scanning, 7500cd / Sqm Description CE Rohs ETL P10 Full Color Video Wall Indoor LED Large Screen Display 1 .

Long service life : light emitting diode longevity in 10 million hours above, 2 .

Fast response : this is the common characteristics of semiconductor devices, 3 .

Visibility distance : the single point: LED to 52mm, visible distance than 500 meters, 4 .

Many varieties : the LED display: indoor and outdoor, have monochrome, double-color, color, 5 .

A high degree of digitalization : can achieve high resolution graph, 6 .

High brightness : can be used in outdoor, such as: the lights, fog lamps, etc.

Technical Parameters - - - -

Item | P10-32X16RGB | Physical Pixel(mm) | 10 | Pixel | 1R1G1B | Physical resolution (dots/m2) | 10000 | Control Method | Constant Current 1/4 Scan | White Balance Brightness (cd/m2) | 7000 | Gray scale | 14bit | Display Color | 687 | Repetition frequency | 60HZ/S | Refresh rate | 1000HZ/S | Brightness'adjustment | R.G.B each 256 grade | Optimum viewing distance (m) | 12m | The best viewing angle (Left&Right/Up&Do wn) | 160/50 | IP | IP54 | Life Span | >100000 h | /LED Module(dots) | 3216 | LED Module Size(mm) | 320160 | Cabinet size (W/H)(mm) | 960960 | Cabinet Net weight(kg) | 47 | Cabinet Resolution(W/H)(dot) | 9696 | Working temperature | -10C~+40C | Working Voltage | 220/110VAC, 50/60Hz | Maximum power consumption (W/ m2) | 850 | Transmission control system | DVI graphics card + master card + optical fiber transmission (optional)transmission or Rj45 (optional) | Video signal | S-VHS, DVD, TV, Satellite, Color-camera, PC-VGA | Spare parts | Leds, IC, cables etc.

| Certificates | CE, ROHS, CCC | Software | LED studio | - - - - Advantages - - - -

8 Years Warranty | The longest warranty time offers you the best security of purchase.

| - - - - - - - -

Lighter & Thinner | | Save about 1/2 receiving cards.

Save 1/3 transportation cost.

Save installation material, labor and time.

| - - - - - - - -

Diagnostic indication | Visible mistake tracking function.

| - - - - - - - -

Back-up Power Supply | | Guarantees the continuous working of display, even when one of power supply fails, improve the stability of display; Special power pack design, increase lifespan of power supply | - - - - - - - -

Fast Set-up | -Inside power cable connection change from screw fixture to plug and play -Only require 1/5 installation time of traditional cabinets.

-Protect operator from potential electric shock, much safer than traditional cabinets.

| - - - - - - - -

Energy Saving | | -Average power consumption 200w/sqm only -Save 0.2 KWH per sqm by each hour | - - - - FAQ Q1 : How would I do when something was wrong with the screen? A1 : Professional engineers would offer onsite maintenance to your country.

Q2 : How would I select LED screen that I need? A2 : The lower Pixel pitch, the more density, the more clear, the more expensive as well.

Q3 : Where LED screen can be applied? A3 : It is seen everwhere in your life.

Mall advertising;bank queue system, taxi top board, stage backgrounddisplay and more.

Application
