High Refresh Rate Smd 3535 P6 Outdoor Full Color Led Display Waterproof - China

High Refresh Rate SMD 3535 P6 Outdoor Waterproof Full Color LED Display Product Description P4, P5/P6/P8/P10 outdoor LED screen adopts physical and virtual pixel technology which makes the picture more clear and vivid, no flicker and blind dots.

The screen is manufactured in a waterproof and dustproof design so it can work very well in rain and sunshine.

It can be assembled and disassembled very easy, and it is an ideal product for any kind advertisements.

It characterized by perfect vivid image, super brightness, high refresh rate, long life span and stable work, and waterproof, etc.

It is widely used in advertising, sports, industrial enterprise, transportation, stations, terminals, airports, construction, education system and other public places.

Main advantages: 1 - New mask design makes LED light almost zero reflection, which ensures the screen displaying effect; 2 - The cabinet of unit modules adopts to high-temperature spraying technology, the antirust function is greatly improved; 3 - Module surface flatness 0.2mm, the entire screen has good flatness; 4 - High uniformity display color; 5 - For improving the service life, PCB is made by wave soldering process with the green oxygen isolation layer, which prevents the line of moisture and oxidation.

6 - Service efficiency of the screen switch power supply is increased substantially, which reduces power failure rate; 7 - Using fishbone bus line greatly reduces the contact problem; 8 - IP65 grade for high performance waterproof and dustproof capability; 9 - -25C 65Cworking environment for outdoor display, adapted to the harsh environment.

Specification: - - - - Item | Parameter | Pixel | Physical pixel pitch: 6 mm | Pixel configuration: 1R1PG1PB | | Wave | Packing | R | 620-625nm | SMD-3535 | G | 520+/_1.25nm | SMD-3535 | B | 470+/_1.25nm | SMD-3535 | Module | Module size: 192 x 192 mm | Module resolution: 32 x 32pixel | Cabinet | Cabinet size: 768x576x150 mm | Cabinet resolution: 128 x 96pixels | Cabinet density: 12288 pixels | Module quantity: 12 pcs | Material: Iron | Weight: 40Kg | Average power consumption: 300W | Max power consumption: 700W | Electricity parameter | Brightness: 6000 nits | Brightness adjusted: 100 grade by software, or by Auto-optic induced | Color processing: 16bit | Display color: 280 trillion | Color temperature(k): 5000 9500 (choice by user) | Physical density: 27777 pixels/sqm | Whole display flatness: 1mm juncture | Best view distance: 7m | Best view angle: Horizontal 80, Vertical 80 | Storage temperature: -35 ~ +85 Working temperature: -20 ~ +50 | Driving method: Constant driving current Scan: 1/4 | Refresh frequency: 1200Hz | Frame rate: 60Hz | Humidity(RH): 90~95% | Protection grade: IP65 | Power supply: AC 110 / 220V, 50/60Hz | Average power consumption: 400W/sqm | Max power consumption: 900W/sqm | MTBF: 10, 000 hours | Screen lifetime: 100, 000 hours | Control system | Signal interface: DVI | Communication distance: Internet cable: 120m Fiber cable: 1000m | Signal transfer mode: Pixels to pixels display synchronized | - - - -
