Indoor P5 Smd Led Display Screen Full Color High Brightness 140 Viewing Angle - China

P5 indoor LED video wall display indoor LED display board Product Description 1 - Professional lock design makes seamless connection available 2 - Full color, SMD 3-in-1 LED design, 140 viewing angle, high brightness 3 - Information source can be camera, video, VCD, DVD, LD, TV and so on; Clear picture without flicker and distortion 4 - Black LED and light absorbing mask patent increase the display effect 5 - Accurate, fast and flexible installation positioning can take place in different area 6 - High definition guarantee excellent performance Specifications: - - - - Technical parameters | S/N | Module Specification | 1 | Pixel Pitch | 5mm | 2 | Pixel Configuration | 1R1G1B | 3 | LED Type | SMD2121 | 4 | Pixel Density | 40000 pixel dots/s.q.m | 5 | Module Size(W X H) | 320mm x 160mm | 6 | Module Resolution( W X H) | 64 pixel dots x 32 pixel dots | 7 | Input Voltage(DC) | 5V +/- 5% | 8 | Cabinet Specification | 9 | Cabinet Size(W X H) | 960mm x 960mm | 10 | Cabinet Resolution(W X H) | 192pixel dots x 192 pixel dots | 11 | Unit Cabinet Weight | 30kg(without packaging) | 12 | Whole Screen Specification | 13 | Screen Brightness | Min.

1700nits/s.q.m | 14 | Driving Mode | Constant current 1/16 driving | 15 | H/V Visual Angle | 140deg.

/70deg.

| 16 | Minimum Viewing Distance | 5m | 17 | Max.

Power Consumption | 850W/s.q.m | 18 | Average Power Consumption | 700W/s.q.m | 19 | Gray Level | 4096 levels | 20 | Blind Spot Rate | Max.

1/10000 | 21 | Power Supply Mode | AC220 +/- 10% 50Hz/AC110 +/- 10% 60Hz | 22 | Environment Temperature & Humidity | Temperature -20 Celsius degree~+60 Celsius degree Humidity 10%~90% RH | 23 | Control System | 24 | Operating Environment | Operating system Chinese/English Windows98/me/2000/NT/XP Hardware Configuration Pentium 300MHz or above ROM 64M Graphics Card Standard VGA 256mode or above Related Software Microsoft Media player compulsory OFFICE2000 in case of *.

doc files RealPlayer in case of RealPlayer files | 25 | Software | LED Studio | 26 | Control Mode | Synchronization display(work with computer) | 27 | Control System | DVI video card + full color control card + fiber system( optional) | 28 | Display Content | Video DVD, VCD, TV, image, texts.

etc.

| 29 | Interface | Standard Ethernet | 30 | Transmission Distance | CAT5 cable: <100 m; Single fiber: <10 km | - - - - FAQ: 1 - Can you assign engineer to our site to guide the installation if we require? Yes.

We have qualified and experienced engineers who are ready to service for you.

2 - How about your warranty and after-sale policy? Two years warranty is free.

We provide 24 hour phone answering service and real-time remote control service if you have any problem with our led screen.

3 - How long time I can get the cargos after placing the order ? Our production time is about 7~ 15 working days; When we confirmed the order, after we get your deposit, we can start production, we will update the production details in time; Before finish, we will notice you and after we get full payment, we can delivery the goods to you.

About the time from start port to destination, that depends on the distance and the state of the sea company or airport company 4 - What's the difference of DIP(1R1G1B) and DIP(3 in 1) ? DIP(One LED, 3 in 1) LED Display, one pixel has one LED lamp, 3 led chips in one LED Lamp; Traditional DIP( 1R1G1B) use 3 LED Lamp in one pixel.

5 - How I can make payment? We support T/T, West Union and so on.

And about payment, we need you pay us 30% as deposit, for the rest part, before delivery.
