Low Transportation Costs 40w Economical Led Road Light - China

Series Kmini LED Street Light

Model：

ZGSM-LD40Kmini+

Economical LED Street Light Application：

Street | Road | Highway | Parking lot | Bridge | Path

European Style LED Street Light KEY FEATURES

● Wide power range: 20W~50W.

● Special circuit design, single LED's damage won't affect others' normal work.

● Smart design, low transportation costs.

● Smooth body would greatly diminish dust accumulation and bird droppings heap up.

● High Lumen output up to 160lm/ w with high quality LED chips.

● Multiple lighting control options are available, e.g. 1-10V, photocell.

● Designed to last at least 100, 000 hours at L70.

We also provide Tool Less LED Street Lights, UL Certified LED High Bay Light, 120w led high bay light, Tennis court led flood light and soon.

ZGSM is a hi-tech and private Enterprise devoted to R&D, producing and selling of Economical LED Street Light, Building led high bay light, Lithium Battery Solar Power System and so on.

As one of the patent model enterprises and the first batch of Energy-saving Service Company in Zhejiang Province, we have registered more than sixty products; we are also the members of Illuminating Engineering Society and Semiconductor Industry Association in China.

SPECIFICATIONS

Specifications

Model ZGSM-LD50Kmini

LED Brand LUMILEDS® LUXEON 3030/ 5050

Driver Brand Inventronics

Norminal Wattage 50W

LED Chip Quantity 3030: 80pcs 5050: 28pcs

Input Voltage 100-240/277VAC

Power Efficiency >90%

Power Factor >0.95

Lamp Rated Luminous Efficiency 3030: 142 lm /w 5050: 150 lm /w

Lamp Rated Lumen output 3030: 7100 lm 5050: 7500 lm (Lumen tolerance +/- 5%)

Color Rendering Index 70(80 optional)

Color Temperature 3000K or 4000K or 5000K or 5700K

Photometric Type 3030: Type II Medium 5050: Type II Medium BLS

Optimal Operating Temperature 25℃

Storage Temperatures -40°C~50°C

Working Environment Between-40°C~+50°C, 10%~90%RH

Total Harmonic Distortion < 10%

Lumen Maintenance > 100, 000 hours -L70, @25 ºC (77 ºF)

Wind Index Force 12

Body and Shell Materials Die-cast aluminum; PC Lens

Pole Fitter Diameter 60mm ( 50mm optional)

Rating IP66 IK10

Protection Class I

SPD 10KV (20KV optional)

Certification CE, ENEC, CB ROHS, LM80, LM79, IP66 IK10, ISTMT

Dimming Options 1-10V

Control Options Photocell or Smart control

Color Options Deep grey

Warranty 5 years
