Waterproof Outdoor Led Screens 1 5 Scan Panel P8 Advertising Rgb Video Billboard - China

Waterproof Outdoor LED Screens 1 / 5 Scan Panel P8 Advertising RGB Video Billboard - - - - Model | P8 LED Screen | Pixel pitch | 8mm | Pixel density | 15, 625 dots /sqm | Module size(W*H) | 320 mm(width)*160 mm(height) | Module pixels(W*H) | 40 dots *20 dots | Pixel configuration | 1Red 1Green 1Blue | Drive mode | constant current driving 1/5 scan | LED lamp type | Water-proof SMD3535 | Cabinet size(W*H*D) | 640mm*640mm | Cabinet resolution | 80*80 | Color scale | 65, 536 degree | View angle(H/V) | 140/120 degree | Brightness (White balance) | about 6500cd/sqm.

| Power consumption(one cabinet) | Max: 700W/sqm.

Average: 200W/sqm.

| Inputting voltage | 90-264VAC, 47-63 VAC | Net weight | 13Kg/cabinet | Operating temperature | -30C+60C | Operating humidity | 10%-95%RH | Life time | 100, 000hours | MTBF | 5, 000 hours | Whole Display Flatness | 0.5mm Juncture | Frame frequency | 25-60 Hz/s | Refresh rate | 2000Hz /s | Control distance | 100m (without repeater), single mode fiber: 20km, multi mode fiber: 500m | LED control system | LINSN, Dbstar, Nova-star, ZDEC, Colorlight is selectable | Operating system | Windows 2000 / Windows Xp / Windows 7 / windows 8 /8.1 / windows 10 | Protection grade | IP65 | Maintenance way | Rear Access | Accepting signal with video processor | PAL/NTSC/SECAM, S-Video;VGA;RGB;Composite Video;SDI | - - - - Feature : 1 .

Good LEDs: Our factory LEDs has excellent performance in antistatic ability and UV protection; Waterproof SMD 3 in 1 LED lamp: IP65 grade, all-weather available 2 .

Energy saving: Low electric current, high-bright lamps, equipped with PFC switching power supply, save 30% electricity.

3 .

High refresh rate, high gray level: It can reach 16bit by using PWM driving IC, refresh rate is more than 4000HZ, the gray level is still high even under the condition of low brightness.

4 .

Color correction: Support dot-to-dot correction, guarantee the consistence of LED color and brightness, No chromatic aberration for new screens.

5 .

Dual back-up: Both power supply and system dual back-up are optional, reliable performance 6 .

Detection and monitoring: It can monitor the inner temperature, voltage, coolingfans Etc and error detection automatically.

Advantage : 1 .

Excellence effect: high definition, high resolution, very applicable to the outdoor high density display 2 .

Flexible mode of operation: any layout mode by the user 3 .

Wide Angle: 120 visual Angle, suitable for wide distribution and high level gap between the larger environment 4 .

Stable performance: superior anti UV, sulfide resistant ability, can be long-term used in outdoor 5 .

Efficient waterproof: outdoor waterproof processing, waterproof level can reach IP65; 6 .

Three anti-protection: anti-corrosion, anti-static, moisture, shock, greatly improving the reliability of the product.

Applications : Our full color LED display are widely used in commercial advertising, entertainment industry, financial industry, communications, power sector, traffic, stadium, plaza, school, airport, bus station etc., for advertising and displaying messages.

Shipping : We will recommend the suitable shipping and delivery method as to goods condition.

1 .

By Ocean shipping 2 .

By Air transport 3 .

By Express such as DHL / FedEx / UPS / TNT Our safe and reliable package can guarantee safe transportation and delivery for your goods.
