Hybrid Combined Slip Ring Manufacture In China - China

Hybrid slip ring is designed for setup at the end of shaft or side of the machine, fit for passing fluid + signal or low current power.

The slip ring is set in the body of rotary joint, and the wires of rotor lead out from the center.

Rotor side has flanges for setup.

A Feature: 1) High quality bearing on both sides of shaft for smoothly operating;

2) High quality sealing materials for long life circle;

3) Special finished shaft provides a excellent wear resistance;

4) Al, Bass, stainless steel body for option;

5) Specially designed leak detection holes;

6) No need to maintain.

B.

Technical specification:

Speed: 100Rpm

Operate temperature: -30～90℃

protect degree: IP54

Housing: Al alloy Part A: (Electornic Slip Rings)

Channels: 12 rings(for signal)

Operation Voltage: 0~240VAC/DC

Current: 2A/Ring

Contact material: Precious Metal

Electric Noise: Max.

40m Ω

Dielectric strength: 500VAC@50Hz, 60s

Insulation resistance: 500MΩ @600VDC

Part B: (Rotary Joint)

Channels: 2 Ways

Pressure: 1.6Mpa Max

Media: compressed air/ vacuum Our products are widely used in: Security, Factory Automation, Electric Instrumentation, Medical, Aerospace, Marine, Civil and Military Fields.

Such as: Crane, Giant Wheel, Cotton Picker, Medical Equipment, Detector, Rotary Tables, Robots, Strander, Webcam, Automatic Revolving Door, Exhibit / Display Equipment, Food Manufacturing Machine, Packaging Machine, Amusement Equipment, Irrigation Machine, Heated Rollers etc.
