Rosemount Black Battery Pack 701pbkkf - China

Black Emerson 701PBKKF Smart Power Module

Rosemount black battery pack 701PBKKF With up to 10-year, maintenance-free operation, the Emerson 701P SmartPower? Module - Black provides replacement without transmitter removal allowing you to quickly change power modules in the field.

As an intrinsically safe solution, this power module is engineered with a robust and adaptable design that withstands harsh environments and allows you to choose the best mode of power for your application.

Specifications Functional specifications Life expectancy

Up to 10-year life at 1 minute update rate.

Humidity limits

0–100% relative humidity Physical specifications Material selection

Emerson provides a variety of Rosemount product with various product options and configurations including materials of construction that can be expected to perform well in a wide range of applications.

The Rosemount product information presented is intended as a guide for the purchaser to make an appropriate selection for the application.

It is the purchaser’s sole responsibility to make a careful analysis of all process

parameters (such as all chemical components, temperature, pressure, flow rate, abrasives, contaminants, etc.

), when pecifying product, materials, options and components for the particular application.

Emerson Process Management is not in a position to evaluate or guarantee the compatibility of the process fluid or other process parameters with the product, options, configuration or materials of construction selected Electrical connections

Emerson SmartPower solutions were designed for use with various Smart Wireless devices.

The black power module is used with the 3051S, 648, 848, 702, 2160, 9420, and 6081.

The green power module is used with the 708, 3051C, and 2051 - Rated voltage

Black Power Module: 7.2 V

Green Power Module: 3.6 V Materials of construction

Lithium-thionyl chloride with a polybutylene terephthalate(PBT) enclosure.

Weight

Black Power Module -0.50 lb.

(230 g)

Green Power Module - 0.34 lb.

(155 g) Performance specifications Electromagnetic compatibility (EMC)

All Models:

Meets all relevant requirements of EN 61326-1; 2006; EN61326-2-3; 2006 - Vibration effect

No effect when tested per the requirements of IEC60770-1: High Vibration Level - field or pipeline (10-60 Hz 0.21 mm displacement peak amplitude / 60-2000 Hz 3g).

Power module life

Power module life in a given wireless transmitter is mainly a function of the wireless update rate.

Faster wireless updates lead to lower power module life.

Power module life is also impacted by extreme temperature service and wireless network conditions.

Assumptions

? 3 Network Descendants

? 70 °F Ambient Temperature

? 10 years is shelf life of lithium cell

? +/- 10% capacity for temperature and network variation Black power module ? Hazardous Area Certifications: FM, CSA, ATEX, IECEx Designed for use with:

Rosemount 702 Wireless Discrete Transmitter

Rosemount 3051S Wireless Pressure Transmitter

Rosemount 648 Wireless Temperature Transmitter

Rosemount 848T Wireless Temperature Transmitter

Rosemount 248 Wireless Temperature Transmitter

CSI 9420 Wireless Vibration Transmitter

Rosemount Analytical 6081 Wireless Transmitter for pH andConductivity

Rosemount 2160 Wireless Vibrating Fork Liquid Level Switch

Rosemount 3308 WirelessGuided Wave Radar Level and Interface Transmitter Green power module Hazardous Area Certifications: FM, CSA, ATEX, IECEx Designed for use with:

Rosemount 708 Wireless Acoustic Transmitter

Rosemount 3051 Wireless Pressure Transmitter

Rosemount 2051 Wireless Pressure Transmitter Intrinsically safe power solution

? SmartPower Modules can be changed in hazardous areas

? No need to remove transmitter from process to change powermodule Predictable life

? Life expectancies specified under installed conditions

? Up to 10 year life depending on update rate Easy maintenance

? Low level alerts for easy planning of replacements

? Keyed connections for easy replacement and fail-safe connection Safe robust design

? Short circuit protection

? No special training required

? Designed for harsh environments Features Up to 10-year, maintenance-free operation and replacement without transmitter removal for reliable performance Adaptable module offers a selection of power modes to meet varying application demands Intrinsically safe device designed for routine maintenance in hazardous areas Low level alerts allow easy and straightforward maintenance scheduling Keyed connections provide easy and fail-safe replacements Ordering Information Model Product description

701P SmartPower Options SmartPower type

BK Black Power Module GN Green Power Module Certification

KF FM, CSA, ATEX, and IECEx Intrinsically Safe Typical model number: 701PBKKF
