Sirf V Gps Module Engine Board With Mcx Sma Connector Ct G340 - Taiwan

The Ct-G340 w/Ct-G530P module is high performance, low power GNSS receiver, based on the SiRFStarVTM single chipset technology while providing fast time-to -first-fix.

Its far reaching capability meets the sensitivity requirements of car navigation as well as other location-based applications.

Ct-G340 w/Ct-G530P is designed to allow quick and easy integration into GPS-related applications, especially for compact size devices, such as:

- Fleet Management / Asset Tracking

- AVL and Location-Based Services Performance

- GPS, GLONASS, Galileo, BDS and SBAS reception for high GNSS availability and accuracy

- 52 track verification channels

- Active Jammer Remover, removes in-band jammers up to 80 dB-Hz

- Multimode A-GPS (Autonomous, MS-Based, and MS-Assisted), need operator support.

- SiRFGeoRecovTM Reverse EE makes positioning process being done under power saving mode.

- RF Metal Shield for best performance in noisy environments

- High sensitivity navigation engine (PVT) tracks as low as - GPS: -165dB, - GLONASS: -161dBm

- SBAS (WAAS, EGNOS, QZSS, MSAS, GAGAN)

- Tracks up to 8 CW jammers

- Enbedded CGEE/SGEE (With back-end server support) speed up TTFF a lot and makes cold start time to be around 20+ seconds.

- Reacquisition Time: 0.1 second Hardware and Software

- Based on the high performance features of the SiRFstarV™ low power single core logic.

- Adaptive micropower controller

- Only 50 to 500μA maintains hot start capability (core logic)

- <10mW required for TricklePower™ mode

- RoHS compliant (lead-free)

- Dimension : 40.64 x 71.12 x 1.4 mm
