Coin Cell Battery And Charging System Tester Highly Dynamic Measuring Equipment - China

Neware Coin Cell Cycle Life Tester Battery Analyzer for Charge and Discharge Testing Brief Introdution: Neware Battery Tester Cycle tests provide information about the battery such as its internal chemistry, capacity, number of useable cycles, and lifetime.

In production testing, a discharge/ charge cycle is often performed to verify battery specifications and to ensure it is not defective.

BTS 4000 - Advanced Testing System HPPC, Capacity, Cycle Life, Formation & Grading, Over-charge, Over-discharge Market-proven Testing System <=20ms Response Time to Meet Rapidly Changing Power Requirements 0.1% Full-scale Accuracy for Current & Voltage 10Hz Data Acquisition Frequency, 100Hz Optional 500ms Minimum Pulse Width More Than 1 Million Records Can Be Processed Voltage and Current Range: 25mV~5V, Range 1: 5uA~1mA;Range 2: 1mA~10mA) 8 channels for each unit, and have the ability to test up to 80 coincells with a single chassis.

Specification: - - - - BTS-5V10mA Double Range Battery Testing System | Project Index | Parameter Index | Input Power | AC 220V 10% / 50Hz | resolution | AD: 16bitDA: 16bit | Input Resistance | 10G | Voltage | Per Channel Control Voltage Range | 50mV~5V | Minimum discharge voltage | 0V | Accuracy | 0.05% of FS | Stability | 0.05% of FS | Current | Per Channel Current Range | Range 1: 5uA~1mA Range 2: 1mA~10mA | Constant current cut-off current | 0.05% of FS | Accuracy | 0.02mA | Stability | 0.05% of FS | Power | Per Channel Output Power | 0.05 | W | Stability | 0.1% of FS | Time | Current Response Time | 1ms | Step Time Range | (365*24 )hour/step, Time Form Support 00: 00: 00(h, min: s, ms) | Data Recording | Record Condition | Timet: 100ms | VoltageU: 10mV | CurrentI: 0.02mA | Record Frequency | 10Hz | Charge | Charge Mode | Constant Current Charge, Constant Voltage Charge, Constant Current and Constant Voltage Charge, Constant Power Charge | End Conditon | Voltage, Current, Relative Time, Capacity, -V | Discharge | Discharge Mode | Constant Current Discharge, Constant Power Discharge, Constant Resistance Discharge | End Condition | Voltage, Current, Relative Time, Capacity, -V | Pulse Test | Charge | Constant Current Charge, Constant Power Charge | Discharge | Constant Current Discharge, Constant Power Discharge | Minimum Pulse Width | 500ms | Pulse Number | 32 diffirent pulse for a single step | Charge And Discharge Switch | continuous switched for a single pulse step | End Condition | Voltage, Relative Time | DCIR Test | Supported | Cycle | Loop Measure Range | 1~65535 times | Max Steps Per Loop | 254 | Nested Loop | Nested loop Function, Max Support 3 Layers | Protection | Software Protection | # Power-down Data Protection | # Off-line Testing Function | # Setting Protection Condition, Setting Parameter: Low Voltage limit, Upper Voltage limit, Low Current limit, Upper Current limit, Delay Time | Voltage and Current Testing Sample | 4-wire connecting | Noise | <85dB | Database | MySQL Database | A Means of Communication of Upper Machine | TCP/IP Protocol | Data Output | EXCEL 2003, 2010, TXT | Communication Interface | Internet Access | Server Operating System | Windows 7 | Leak Current | 0.0000005mA | Per Unit Main Channels No.

| Per Unit Main Channels No.

| - - - - Primary Applications: Current & Voltage Measuring Pulse Test Supported Direct Current Internal Resistance Test Capacity and Specific Capacity Cycle Life Formation & Grading Over-charge, Over-discharge Highlights: # # Extremely precise and highly dynamic measuring equipment # HPPC, Capacity, Cycle Life, Formation & Grading, Over-charge, Over-discharge # Market-proven Testing System # <=20ms Response Time to Meet Rapidly Changing Power Requirements # 0.1% Full-scale Accuracy for Current & Voltage # 10Hz Data Acquisition Frequency, 100Hz Optional # 500ms Minimum Pulse Width # More Than 1 Million Records Can Be Processed # 'And', 'or', '', '' and '=' supported; # Condition switches works with step accumulated time; # Up to 5 condition switches for each step; # Go to break supported.

# Fast measure speed, wide measure range.

# For testing all kinds of battery including Li-ion battery, NiMH, NiCd, battery pack, and etc.

# Our equipment is designed for both laboratory and production scale applications, including formation and ranking.
