High Accuracy Neware Battery Testing System - China

Neware BTS-9000 for Battery Material Test System 0.05% High Accuracy BTS9000 is based on Neware 6th-generation testing system.

Its designed for battery material research, high-precision tests, pulse charge/discharge tests, DCIR test, and cycle life test.

As the most cutting-edge equipment for battery material research, BTS9000 comes with extremely high accuracy(0.02% of FS), amazing hardware response speed(100s), wide range of applications, high-speed testing data acquisition and many other industry-proven characteristics, its your ultimate choice for battery material research! BTS9000 is the most advanced battery testing instrument from Neware, its the best choice for material research Extremely high accuracy(0.02% of FS) Hardware Response Time: 100s Min pulse width: 400s Adaptable to a wide range of products (cells, batteries, super-capacitors and battery modules, etc.

) Wide range of applications (grading, over charging/discharging, ladder-type charge/discharge, pulse) DCIR, HPPC and GSM Pulse tests supported.

It characterized with a data acquisition frequency up to 1000Hz, an accuracy of 0.02% FS and a minimum pulse width of 400us (microsecond) which can be utilized for GSM or some other rapid pulse tests.

Comes to the pulse tests, BTS9000 supports GSM(Global System for Mobile Communications), GPRS(General Packet Radio Service), CDMA-standby, CDMA-talk(Code Division Multiple Access), IDEN(Integrated Digital Enhanced Networks), etc.

4 Channels a unit, and more channels for a rack or a station can be customerized.

CT-9004-5V5A Specifications: - - - - Project index | Parameter index | Input Power | AC 110V 10% / 50Hz | resolution | AD: 16bitDA: 16bit | Input Resistance | 1M | Input Power | 250W | Channel Features | Four Ranges, Wide Dynamic Range, High Speed Sampling, High Accuracy | Channel Control Mode | Independent Control | Voltage | Per Channel Control Voltage Range | Charge: 0.7V~5VDischarge: 0 .

7V~5V | Minimum discharge voltage | 0.7V | Accuracy | 0.02% of FS | Stability | 0.005% of FS | Current | Per Channel Current Range | Range 1: 0.1uA---150uA Range 2: 145uA---5mA Range 3: 4.5mA---150mA Range 4: 145mA---5A | Constant current cut-off current | Range 1: 30nA Range 2: 1uA Range 3: 30uA Range 4: 1mA | Accuracy | 0.05% of FS | Stability | 0.05% of FS | Power | Per Channel Output Power | 0.05W | Stability | 0.1% of FS | Time | Current Response Time | 20ms (0-Full Range) | Step Time Range | (365*24 )hour/step, Time Form Support 00: 00: 00(h, min: s, ms) | Data Recording | Record Condition | Timet: (100ms ~60000s) | VoltageU: (10mV~5V) | CurrentI: (0.02mA~10mA) | Record Frequency | 10Hz | Charge | Charge Mode | Constant Current Charge, Constant Voltage Charge, Constant Current and Constant Voltage Charge, Constant Power Charge | End Conditon | Voltage, Current, Relative Time, Capacity, -V | Discharge | Discharge Mode | Constant Current Discharge, Constant Power Discharge, Constant Resistance Discharge | End Condition | Voltage, Current, Relative Time, Capacity, -V | DCIR test supported | Pulse Test | Charge | Constant Current Charge, Constant Power Charge | Discharge | Constant Current Discharge, Constant Power Discharge | Minimum Pulse Width | 500ms | Pulse Number | 32 diffirent pulse for a single step | Charge And Discharge Switch | continuous switched for a single pulse step | End Condition | Voltage, Relative Time | Cycle | Loop Measure Range | 1~65535 times | Max Steps Per Loop | 254 | Nested Loop | Nested loop Function, Max Support 3 Layers | Protection | Software Protection | # Power-down Data Protection | # Off-line Testing Function | # Setting Protection Condition, Setting Parameter: Low Voltage limit, Upper Voltage limit, Low Current limit, Upper Current limit, Delay Time | Hardware Protection | Additional Anti-reverse Protection Model | Voltage and Current Testing Sample | 4-wire connecting | Noise | <85dB | Database | MySQL Database | A Means of Communication of Upper Machine | TCP/IP Protocol | Data Output | EXCEL 2003, 2010, TXT | Communication Interface | Internet Access | Server Operating System | Windows 7 | leak current | 0.0000005mA | Per Unit Main Channels No.

| 8 | Dimensions(W*D*H)(mm) | 3U(19) | - - - - 1 - Resolution: AD: 16bit; DA: 16bit; 2 - Accuracy : 0.02% FS; 3 - Response Time: 100us (Current in the range 10%~90% FS); 4 - Data Acquisition Frequency: 1000Hz; 5 - Minimum Pulse Width: 400us; 6 - Voltage Range: 5V; 7 - Current Ranges: Range 1: 160uA 32nA Range 2: 5mA 1uA Range 3: 160mA 32uA Range 4: 5000mA 1mA Primary Applications: # Electrochemistry, Battery & Supercapacitor Testing # Electrochemical Research and Development # HalfCell Charge and Discharge Testing # Life Cycle Testing # DCIR Testing(direct current internal resistance) # HPPC Testing Equipment Pictures: Neware Battery Testing System, Battery Cycler, Battery Charge and Discharge Station.
