High Power Neware Battery Cell Tester - China

High Power Battery Tester 5V / 40A Certificated by CE and ISO9001 Specifications: - - - -

AC Input | AC 220V10% 50Hz | Power | 2987 | W | Resolution | AD: 16bit; DA: 16bit | Impedance Input | 1M | Voltage | CV control range | 0.025V~5V | | Discharge Min Voltage | 2.5V | Accuracy | 0.1% of FS | Stability | 0.1% of FS | Current | Range | 0.2A~40A | Accuracy | 0.1% of FS | Cut-off Current of CV | 0.08A | Stability | 0.1% of FS | Power | Output Power Per Channel | 200W | Stability | 0.2% of FS | Time | Rise Time | 20ms (0~Full Range) | StepTime | (365*24) hour/step | Time Format 00: 00: 00: 000 (h: min: s: ms) | Data Acquisition | Intervals | Time interval t: (100ms~60000s) | Voltage interval U: (10mV~5V) | Current interval I: (80mA~40A) | Frequency | 10Hz | Charge | Modes of Operation | CCC, CVC, CC & CVC, CPC | End Conditions | Voltage, Current, Test Time, Capacity, -V | Discharge | Modes of Operation | CCD, CPD, CRD | End Conditions | Voltage, Current, Test Time, Capacity, -V | Pulse | Charge | CCC | Discharge | CCD | Minimum Pulse Width | 500ms | Automated Switch | Automated switch from charge to discharge for each pulse | End Condition | Voltage, Test Time | Cycle | Cycles | 65535 | Steps | 254 | Nested Function | Max three levels of loops | - - - - Features: - - - -

Protective Function | Software | Power-off data protection | Off-line Operating | User-defined safety (upper and lower) tolerance of current, voltage and delay time | Hardware | Reverse-connecting protection | Channel Features | Independent pairs of closed loop for constant current source and constant voltage source | Channels | Independent control | Detection and Sampling | 4-wire Connecting | Noise Density | <85dB | Data Management | MYSQL Database | Communication Means | TCP/IP Protocol | Exports Formats | EXCEL, TXT, Graph | Communication Interface | Ethernet Port | Number of Channels Per Cabinet | 8 | - - - - Operating Environment: - - - -

Operating Temperature | 0~40 | Storage Temperature | -10~50 | Operating Humidity | 70% RH | Storage Humidity | 80% RH | - - - - Clamps for Battery Connection:

# # Universal Holder

# Alligator Holder

# Polymer Holder

# Wiring Terminal Primary Applications: Current & Voltage

DCIR Test

Charge and Discharge Capacity Test

Cycle Life

Formation & Grading

Over-charge, Over-discharge

Reliable hardware with independent constant current and voltage control

Pulse Test with CCC and CCD Mode

Battery Temperature Meaturement Product Deatail Information:

# # Place of Origin: Shenzhen, China (Mainland)

# Brand Name: Neware

# Model Number: CT-4008-5V30A-NF

# Input Voltage: AC 220V 10% / 50Hz

# Input Power: 2127W

# Voltage and Current Testing Sample: 4-wire connecting

# Noise: <85dB

# Per Unit Main Channels No: 8

# Channel Control Mode: Independent Control

# Input Resistance: 1M

# Dimensions: 12U, 482*508*378(mm)

# Warranty: One year limited warranty with lifetime support

Company Contact:

• Posted By: Neware Technology Limited company

• Phone: 86-755-83109966

• Address: 15/F, Tower 3, Excellence City, No.128, Zhongkang Rd., Shenzhen, CHINA 518049, Shenzhen , guangdong , China

• Email:

• Website: https://newarebattery-tester.sell.everychina.com

• Business Description: Introduced to the market in 2006, the most cost-competitive cell and battery test equipment, BTS3000 is now the most popular type in the battery testing field, and it serves for research institutes, universities and battery manufacturers all around the world.
