Ip65 Waterproof Solar Based Led Street Light With Auto Intensity Control160lm W - China

Led Street Light With Solar Panel Motion Sensor Automatic Control IP65 Waterproof Features 1 - Beautiful and modern appearance, simple and fashionable.

2 - Use of solar green energy, environment friendly, saving more.

3 - Low voltage driving, meet the Europe standard of CE RoHS FCC.

4 - No Hg, Pb or other hazardous materials, no radiation, human safety.

5 - IP65 grade, TVS lightning protection.

6 - Long lifetime of whole lamp, low maintenance costs.

7 - Wireless application-Integrated solar panel, LED, lithium battery, micro-controller and other accessories into one system, simple and stylish.

8 - Micro-computer controlled-Combine light control system and time control system perfectly, ensure whole system more energy-efficient.

9 - Easy installation-No power required, no cables required, easy installation in 5 minutes.

10 - Solar panel angle adjustable-Adjustable in vertical and horizontal direction, ensure maximum efficiency of solar energy conversion.

11 - Lithium battery-Adopt lithium battery to replace traditional gel battery, longer lifetime.

12 - Modular design-All components are modular design and in standardized production.

Battery can be easily replaced if needed.

13 - Low cost-Compared with traditional solar led lights, much lower cost, easy to transport.

14 - Good heat dissipation-Solar panel, battery and light body do not connect directly, they will not conduct heat to each other, to support good heat dissipation and long lifetime.

15 - Extreme light-Light efficiency reach 160lm/w, at same illumination, lower watt available.

Specifications - - - - led street light with solar panel | Type | MS-NH50 | MS-NH65 | MS-NH80 | MS-NH100 | MS-NH150 | MS-NH200 | Lamp power | 15W | 20W | 30W | 40W | 50W | 60W | Solar panel | 50W 18V | 65W 18V | 80W 18V | 100W 18V | 150W 18V | 200W 18V | Lithium battery | 170WH 12.8V | 212WH 12.8V | 340WH 12.8V | 424WH 12.8V | 610WH 11.1V | 808WH 11.1V | LiFePO4 battery | LiFePO4 battery | LiFePO4 battery | LiFePO4 battery | Termary battery | Termary battery | LED qty | 40pcs | 40pcs | 60pcs | 60pcs | 60pcs | 60pcs | Luminous flux | 1800-2100lm | 2500-2800lm | 3600-4200lm | 5000lm-5600lm | 7500-8000lm | 8400-9000lm | Charge time(full sunlight) | 5.5hrs | 5.5hrs | 7hrs | 7hrs | 6.5hrs | 6.5hrs | LED chip | Bridgelux | Color temperature | 3000-6500K | CRI | >70Ra | Light control voltage | 5V | Light distribution | Bat wing with polarized light | Lighting time | 2-3days | Sensor distance | 5-12m | Sensor time | 20-30s | Working temperature | -20 - 60 | Lifetime | >50000 hours | Material | High quality aluminum alloy, die-cast aluminum | Pole top diameter | 76mm | Mounting height | 5-10 meters | Installation spacing | 10-30 meters | - - - - Details Installation The first step: the rotating member is fixed to the solar panel bracket The second step: the roof and solar panels partially fixed The third step: the solar panels fixed on the lamp body, while receiving a good waterproof connector The fourth step: the overall fixed on the pole Applications Parks and Reserves Remote Areas & Bush land Pedestrian & Rail crossings Commercial & Industrial estates Jetties, Pontoons & Boat Ramps Security & Perimeter Lighting Bike Pathways Mine sites, Street, Road, Pathway, Highway Packaging Standard export packaging or customized according to customer requirements
