Long Battery Operation Av6416 Palm Otdr With Powerful File Management - China

Long Battery Operation AV6416 Palm OTDR With Powerful File Management Product Summaries AV6416 palm OTDR is the newest instrument in 41st.

Its mainly used to measure the physical characteristics of optical fiber under test, such as the length, the transmission loss and the splice loss etc.

It can also locate the faults or breaks of optical fiber.

Its widely applied in the manufacture, construction and maintenance in optical fiber communication system.

Mainly features 1 - 1.6m eatra-short event dead zone; 2 - 0.25 high resolution, 65535 sampling points; 3 - Auto measuring with high speed, one-button operation; 4 - Advanced TFT transflective color LCD, visible clearly in outdoor; 5 - Visible fault locating (VFL) 6 - Unique function of updating system on-line, returning to factory is unnecessary.

Specifications - - - - | Main Specifications | Main OTDR Modules | 2101 | 2103 | 3105 | 3102 | Center wavelength | 1310nm/1550nm 20nm | 1550nm/1625nm 20nm (build-in filter) | 1310nm/1550nm/1490nm20nm | 1310/1550nm/ 1625nm 10nm (build-in filter) | Type of optical fiber | SMF | SMF | SMF | SMF | Dynamic Range1 | 28 / 26dB | 26 / 26dB | 28 / 26 / 24dB | 28 / 26 / 25 | Distance Measurement Accuracy | (1m + sample space + measurement distance0.003%) | Event Dead Zone2 | 1.6m | Sampling Resolution | 0.25, 0.5, 1, 2, 4, 8, 16m | Distance Range | 0.5, 1, 2, 4, 8, 16, 32, 64, 128, 256km | Pulse width | 10, 30, 80, 160, 320, 640, 1280, 5120, 10240ns | Loss threshold | 0.01dB | Sampling points | Up to 65k | Linearity | 0.05dB/dB | Memory capacity | 800 traces | Group refractive index setting | 1.00000 - 2.00000 (0.00001 steps) | Display | Color LCD(touch screen) | Interface | USB, Min-USB | Optical Connector | FC/UPC (universal connector) | VFL | 650nm 10nm, 2mW(typical);CW/1Hz | Language | User selectable : simplified Chinese, English, Russian, Korean etc.

(please contact CETC 41st for others) | Power Supply | DC: 15V to 20V(3A), (AC adapter 100240V, 50/60Hz, 1.5A), Built-in Lithium battery: 4400mAh, 7.4V, operating time10 hours3 | Dimensions | 21010060(mm) | Weight | 1 kg Approx.

| - - - - Extra-short event dead zone AV6416 palm OTDR has extra-short event dead zone, which is suitable for testing short optical fiber and pigtail optical fiber.

High-speed auto measurement The function of auto measurement of AV6416 palm OTDR makes it unnecessary to operator to know about the further details of operating.

Simply connect the fiber, press [start], then the result is displayed in a few seconds, you can view the trace and event table.

Powerful file management The products can offer powerful function of file managment.

Besides saving, browsing or deleting files to or from USB stick and built-in memory, it can be connected to laser or inkjet printer based on PCL language, and the testing report canbe printed rapdily and easily.

Standard module The available modules of AV6416 palm OTDR are shown as following: - - - - Ordering number | Operating wavelength | Optical fiber type | Dynamic range | AV6416-1101 | 1310nm | SMF | 28 | AV6416-1102 | 1550nm | SMF | 26 | AV6416-1103 | 1625nm | SMF | 26 | AV6416-1104 | 1625nm(build-in filter) | SMF | 26 | AV6416-1105 | 1650nm | SMF | 26 | AV6416-1106 | 1650nm(build-in filter) | SMF | 26 | AV6416-1107 | 1490nm | SMF | 24 | AV6416-1108 | 1383nm | SMF | 26 | AV6416-2101 | 1310 / 1550nm | SMF | 28/26 | AV6416-2102 | 1550 / 1625nm | SMF | 26 / 26 | AV6416-2103 | 1550 / 1625nm(build-in filter) | SMF | 26 / 26 | AV6416-2104 | 1550 / 1650nm | SMF | 26 / 26 | AV6416-2105 | 1550 / 1650nm(build-in filter) | SMF | 26 / 26 | AV6416-3528 | 1310 / 1550nm | SMF | 28/26 | AV6416-5626 | 1550 / 1625nm | SMF | 26 / 26 | AV6416-3101 | 1310 / 1550nm / 1625nm | SMF | 28 / 26 / 26 | AV6416-3102 | 1310 / 1550nm / 1625nm(build-in filter) | SMF | 28 / 26 / 25 | AV6416-3103 | 1310 / 1550 / 1650 nm | SMF | 28 / 26 / 26 | AV6416-3104 | 1310 / 1550 / 1650 nm (build-in filter) | SMF | 28 / 26 / 25 | AV6416-3105 | 1310 / 1490 / 1550nm | SMF | 28 / 24/ 26 | AV6416-3428 | 1310 / 1490 / 1550nm | SMF | 28 / 24/ 26 | - - - - Options - - - - NO.

| Name | type | note | 1 | USB stick | | Saving measuring data | 2 | Printer | Hp laser Jet P2015d or Hp laser Jet 1022 | Printing traces | 3 | USB cable | | Communicating with PC | 4 | Standby battery pack | Special battery pack for AV6416 palm OTDR | Standby battery | 5 | FC/SC, FC/STConnectors | - - - -
