Auto Controlling 10kva 100kv Dc Ac Hipot Tester 380v Superior Performance - China

price: check with company for price

Auto Controlling 10kva 100kv Dc Ac Hipot Tester 380v Superior Performance

Products Photos Catalog Auto Controlling 10kva Photos Catalog

10kVA 100kV Test Transformer/ AC DC Hipot Tester General information: SXTC-M Series AC/DC Hipot Test Set is suitable for hipot dielectric withstand test on various power electric products, units, insulating material and etc.

Features: Manual/Auto controlling.

Oil, dry, SF6 gas type transformer is seletable according to user's requirements.

High anti interference ability.

High voltage (HV) voltage, Low voltage (LV) current, time, three channels testing ways.

Real time monitoring HV voltage, LV current.

Full protection functions: over-current, zero-starting sound light alarm, power switch protection.

New type time rely, wider time range (1S ~ 99H).

New type current rely, more precise, more reliable.

5kVA and above Testing Transformer with movable iron wheel.

Light weight, small size, easy to move, superior performance.

The control tester can be designed to box type, table type, or cabinet type according to user's testing capacity: 5KVA or below, Box type 10KVA or above Table type 50KVA or above Cabinet type.

Add rectifying installation to support AC/DC function .

(option) Specifications: Input voltage: AC 220(380)V (customized) LV output: AC 0-250(430)V LV current: 0-5/10/15/50A (customized) Output capacity: 0-3/5/10/15 kVA (customized) HV output: 0-50/100/150/200 kV (customized) HV current: 0-50/100/150/200/500/1000 /2000mA (customized) Timing range: 0-9999S Working temperature: -20C to 50C Voltage precision: 1.5% 1 digit (F.

S) Current precision: 1.5% 1digit (F.

S) Main parameters of SXTC-M Control Unit: - - - - Model | Input Voltage (V) | Capacity (KVA) | Rated Output | HV voltmeter KV/V | Oversize m3(LWH) | Voltage(v) | Current(A) | SXTC-M05 | 220 | 0.5 | 200 | 2.5 | 50/100 | 203020 | SXTC-M105 | 220 | 1.5 | 200 | 7.5 | 50/100 | 263624 | SXTC-M3 | 220 | 3 | 200 | 15 | 50/100 | 264224 | SXTC-M6 | 220 | 6 | 200 | 30 | 50/100 | 604537 | SXTC-M6 | 220 | 6 | 200 | 30 | 50/100 | 534060 | SXTC-M10 | 220 | 10 | 200 | 50/25 | (50/100)/100 | 534065 | SXTC-M15 | 380 | 15 | 400 | 37.5 | (50/100/150)/100 | 534070 | SXTC-M20 | 380 | 20 | 400 | 50 | (50/100/150)/100 | 534384 | SXTC-M25 | 380 | 25 | 400 | 62.5 | (50/100/150)/100 | 534590 | SXTC-M30 | 380 | 30 | 400 | 67.5 | (50/100/150)/100 | 6555115 | SXTC-M40 | 380 | 40 | 400 | 100 | (50/100/150)/100 | 7060115 | SXTC-M50 | 380 | 50 | 400 | 125 | (50/100/150)/100 | 7060115 | - - - - The rated output current is 5 min continuous working.

More information, please kindly contact with us, we can customize the suitable test set according your requirements and give you the best quotation.

Thank you!


Company Contact:


  • Phone: 86-27-83385466

  • Address: Building 8, YuanYuanXin Industrial Park, DongXiHu District, Wuhan, China, Wuhan , Hubei , China

  • Email: Email


Published date: March 21, 2018

  • Business Description: From the date of order placing, we usually need 3-7 working days to manufacturing.

    Located in Wuhan City, the provincial capital of China, Sansion Power is easy to ship the package by the air or ocean.

    Sansion Power also can provide OEM service according your customized.
