2700mhz 4g Lte Indoor Omni Directional Dual Polarization Mimo Ceiling Mount Antenna 4dbi - China

ELECTRICAL

Model DT-OCA698-2700-4-2

Frequency Range 698~960 / 1710~2700 / 1710~ 2700MHz

Gain 2 / 3 / 4dBi

Horizontal Beamwidth 360°

Vertical Beamwidth 80±10°/ 55±10° / 55±10°

VSWR ≤1.5

Polarization Vertical / Vertical / Horizontal

Isolation ≥ 25dB

Non-circularity ± 1 / ± 1.5

Max Power 50W

Nominal Impedance 50Ω

Lightning Protection DC Ground

MECHANICAL

Connector N Female *2 or customized

Antenna Dimension Φ180*130mm

Weight 0.4kg

Antenna Material ABS

Antenna Color White

Working Temperature -40 ~ + 60℃
