3600mhz 3 5ghz Dual Polarization Mimo Panel Antenna 14dbi Indoor Outdoor - China

ELECTRICAL

Model DT-PA3400-3600-14-2

Frequency Range 3400-3600MHz

Gain 14*2dBi

Beamwidth H: 45°, E: 38°

VSWR ≤1.5

F/B Ratio ≥18dB

Polarization Vertical y Horizontal o ±45°

Max Power 50W

Nominal Impedance 50Ω

Lightning Protection DC Ground

MECHANICAL

Connector N Female *2 or customized

Antenna Dimension 190*190*40mm

Weight 1kg

Antenna Color White

Diameter of the Pole Φ40-55mm

Working Temperature -40-+65℃

Rated Wind Velocity 60m/s
