Ip54 Ip66 Ip68 Double Channel Forj Fiber Optic Rotary Joint Cable Slip Ring - China

JARCH IP54, IP66, IP68 Double Channel Fiber Optic Rotary Joint / Fiber Optic Cable Joint With Stainless Steel House JSR-FO-0111S fibre optic rotary joints are small and compact FORJ with OD 10mm, standard, off-the-shelf, available in stock.

It could support 1 channel fiber optics(SM/MM) transmitting on 360° rotating.

Single-channel (both Single-Mode and Multiple-Mode) rotary joints(FORJ) are the most versatile designs the market has ever seen.

The rugged body allows fiber pigtail, ST, or FC receptacles on either the rotor side or the stator side.

One can configure the package to fit his need exactly.

features extremely low insertion loss and impressive return loss performance for both single mode and multimode fibers.

MJ1 are often used with electronic slip ring, call optical-electrical hybrid slipring, transmit power and high speed data.

Wavelength range 850-1650 nm Insertion loss ≤3.5 dB (typical: <0.5 dB)

Insertion loss ripple <+/-1.0 dB Return loss (SM) ≥40 dB

Maximum speed 150 rpm Pulling strength 10 N (900 um buffer)

Start up torque <0.01 Nm Estimated life cycle 200-400 million revolutions

Optical power handling 23 dBm Working temperature -40°C to 85 °C

Storage temperature -50°C to 85 C°C Package style Pigtails on both ends

Housing material Stainless steel Fiber types Single or multimode w/3 mm jacket (Kevlar/PVC)

Connector types FC, SC, ST, SMA, or LC Dimensions 10mm dia.

Weight 2500 g IP rating IP54/IP65

Vibration MIL-STD-167-1A Mechanical shock MIL-STD-810G If you have any questions, please contact us without any hesitation.
