Metal Sheet Industrial Laser Cutting Machine 500w Enclosure Protection System - China

Metal Sheet and Tube Industrial Laser Cutting Machine 500W for Metal Cutting Product Description: - - - - Laser Type | Fiber laser | Laser Brand | IPG / Maxphotonics | Laser Power | 500W (1000W / 2000W / 4000W optional) | Working area | 1500mmX3000mm 1300x2500mm Optional | Working Table | Fixed Working Table | Control System | PMAC full-closed loop servo control | Driving Mode | Double gear rack driving | Idle/Processing Speed | 72m/min / 36m/min | Positioning Accuracy | 0.05mm | Protection System | Enclosure protection | Laser Head | Precitec / Laser Mech | Power Supply | AC220V 5% 50 / 60Hz / AC380V 5% 50 / 60Hz | Total Power | 7KW~11KW | Floor Space | 5.6mX3.2m (fixed table) | - - - - Cutting Pipe Detail Specification: - - - - Cutting Length | 6000mm | Diameter | 20mm-200mm | Min remaining material | 250mm | X axis | 230mm | Y axis | 6500mm | Z axis | 175mm | Position accuracy | 0.05mm | Reposition accuracy | 0.03mm | Max moving speed for X axis | 40m/min | Max moving speed for Y axis | 500mm/s | Acceleration | 1 G | Size(L*W*H) | 12000*1800*2400mm | Weight | 3800kg | - - - - The whole fiber laser cutting machine for metal consist of machine This system consist of machine tool, motion parts, electrical equipment control parts, and other assist parts.

Via control system to operation three axis motion parts, so it can drive to fiber laser cutting head achieve a stable, accurate, and high speed moving; X and Y axis adopt by imported with original packaging high quality and precision HIWIN linear guide rail, working table adopt by square pipe to welding the overall machine, stress relief annealing treat, the max load-bearing of mesa could get 500 KG, it also has universal ball bearing, machine external set up peripheral clamping device, use full enclosed dust proof device, photoelectric sensor, and other precise positioning parts to ensure accuracy of the transmission.

Advantage of RL-3015-500PT Metal Tube Laser Cutting Machine: 1 - Electric-driver motor in rotary device adjust speed freely, Easy-work, low noisy, high rotary speed, high accuracy.

2 - Intersecting line can be cut.

Best choice for tubular construction.

3 - Imported high precision transmission device which is perfectly work with servo system, thus it can make sure cutting precision and efficiency.

4 - Excellent path quality: Smaller laser dot and high work efficiency, high quality.

5 - High cutting speed: cutting speed is 2-3 times than same power CO2 laser cutting machine.

6 - Stable running: adopt top world import fiber lasers, stable performance, key parts can reach 100, 000 hours; 7 - High efficiency for photoelectric conversion: Compare with CO2 laser cutting machine, fiber laser cutting machine have three times photoelectric conversion efficiency.

8 - Low cost: Save energy and protect environment.

Photoelectric conversion rate is up to 25-30%.

Low electric power consumption, it is only about 20%-30% of traditional CO2 laser cutting machine.

9 - Low maintenance: fiber line transmission no need reflect lens, save maintenance cost; 10 - Easy operations: fiber line transmission, no adjustment of optical path.

Applicable materials: Mainly used for cutting carbon steel, silicon steel, stainless steel, aluminum alloy, titanium alloy, galvanized steel sheet, pickling board, aluminum zinc plate, copper and many kinds of metal materials cutting and so on.

Applicable Industry: Sheet metal, hardware, kitchenware, electronic, automotive parts, glass, advertising, craft, lighting, decoration, jewelry, etc Applicable Material: Specially for carbon steel, stainless steel, galvanized steel, alloy, titanium, aluminum, brass, copper and other metal sheets
