3mm Thickness Polygonal Traffic Light Pole Hot Dip Galvanized With Astm A 123 - China

Octagonal Polygonal Galvanized Traffic Signal LightsSteel Pole with Arm Description: Our outdoor galvanized traffic signal lighting poles are made of qualified sheets through bending, forming, automatic welding, hot dip galvanization and powder coating.

We own advanced production lines including flatting machine, steel plate shearer, bending machine, auto-closed up machine, submerged arc welding machine and powder coating line, and our workmanship and quality control are thought highly of by our clients.

Material Applied to the material of general-purpose steel GB/T1591-2008, Q235, Q345, Q420, Q460 used in China.

- - - -

China-GB | America-ASTM | Equivalent | Q235 | Grade D | SS400, S235JO | Q345 | Grade50[345] | S355JR | Q420 | Grade60[415] | S420NL | Q460 | Grade65[450] | S460NL | - - - - Usually we use Q235 or Q345 for traffic signal steel poles.

Specifications - - - -

Height | As request | Application | Street, road, highway, etc.

| Shape | Conical, Octagonal | Lamp Power | 20 W- 400 W (HPS/MH) 220V (+-10%) /50Hz | Arm | No | Lighting Fixture | IP 65 | Working Atmosphere of Lighting Fixture | -35~+45 | Surface Treatment | Hot dip galvanized with ASTM A 123 | Safety | Against earthquake of 8 grade | Wind Speed | 160 Km/Hour | Min Yield Strength | 355 mpa | Min Ultimate Tensile Strength | 490 mpa | Max ultimate tensile strength | 620 mpa | Standard | ISO 9001 | Thickness | 3mm or above | - - - - Manufacturing Our factory owns advanced machines including bending calibration machine, hydraulic plate shearingmachine, shearingmachine, slitting machine, 208T hydraulic straightener, etc.

All insure us to produce steel poles with best quality.

After the fabrication process as cutting plate, bending, forming, automatic welding, drilling holes, we get poles checked before galvanized, hot dip galvanized and powder coating and finally we get poles checked according to client's requirements.

Inspection To ensure the quality, we have Microcomputer Automatic Carbon Sulfur Silicon Analyzer to check the raw material afterpurchasing the steel sheet.

Then we have Physical Performance Test, Mechanical Test, Galvanization Thickness Test, Load Test and Lad Test during and after the manufacturing process.

All the effort is to meet our clients' requirements.

Delivery We normally use 40HQ containers and our Port limit weight for one 40HQ is 26 tons.

Questions & Answers Q : How to place order on traffic signal pole ? A: Customer offers the picture or drawing of the pole, we evaluate the cost of it.

If the customer can't offer drawing, advise the detailed dimentions, we will work with the drawing for confirmation.

Q: What's your MOQ? A: 1 set Q: Whats' your delivery time? A: Usually within 15 working days.

If our factury is busy and your quantity is large, usually in around one month.

Company Contact:

• Posted By: Jiangsu Bosheng Steel Poles Co.,limited

• Phone: 86-510-80326616

• Address: Heqiao Industrial Zone, Yixing City, Jiangsu Province. China., Yixing , Jiangsu , China

• Email:

• Website: https://www.metalutilitypole.com

• Business Description: Jiangsu Bosheng Steel Poles Co., Ltd founded in 2007, Which is the specialized manufacturer of various steel poles including street lighting pole, electric power pole, traffic signal pole, flag pole, wind power pole and microwave communication tower, etc.
