5m 12m Single Curved End Electrical Street Light Pole Above 95 Percent Peneration - China

5m - 12m Curved End Single Arm Galvanized Street Lighting Steel Pole Material All of our material are purchased from famous mill factory to ensure the quality.

# # A mill certificate issued by the mill factory with stamp and signature must be provided before unloading the material in our factory, otherwise we have our reason to refuse the material .

# Before production, all the material must have the chemical and physical analysis to make sure that they have meet the requested strength and component.

Applied to the material of general-purpose steel GB/T1591-2008, Q235, Q345, Q420, Q460 used in China.

- - - -

China-GB | America-ASTM | Equivalent | Q235 | Grade D | SS400, S235JO | Q345 | Grade50[345] | S355JR | Q420 | Grade60[415] | S420NL | Q460 | Grade65[450] | S460NL | - - - - Usually we use Q235 for street lighting steel poles.

Description: - - - -

Height | 8m | Application | Road, Street, Highway, etc | Shape | Octagonal Polygonal | Lamp Power | 20 W- 400 W (HPS/MH) 220V (+-10%) /50Hz | Arm | Single | Lighting Fixture | IP 65 | Working Atmosphere of Lighting Fixture | -35~+45 | Surface Treatment | Hot dip galvanized with ASTM A 123 | Safety | Against earthquake of 8 grade | Wind Speed | 160 Km/Hour | Min Yield Strength | 355 mpa | Min Ultimate Tensile Strength | 490 mpa | Max ultimate tensile strength | 620 mpa | Standard | ISO 9001 | Thickness | 3mm | - - - - Manufacturing Our factory owns advances production lines and machines including bending calibration machine, hydraulic plate shears machine, shears machine, slitting machine, 208T hydraulic straightener, etc.

All insure us to produce steel poles with best quality.

After the fabrication process as cutting plate, bending, forming, automatic welding, drilling holes, we get poles checked before galvanized, hot dip galvanized and powder coating and finally we get poles checked according to client's requirements.

Inspection To ensure the quality, we have Microcomputer Automatic Carbon Sulfur Silicon Analyzer to check the raw material afterpurchasing the steel sheet.

Then we have Physical Performance Test, Mechanical Test, Galvanization Thickness Test, Load Test and Lad Test during and after the manufacturing process.

All the effort is to meet our clients' requirements.

Delivery We normally use 40HQ containers and our Port limit weight for a 40HQ is 26 tons.

Factory Profile

Founded in 2005, Jiangsu Bosheng Steel Poles Co., Ltd located in Heqiao Town Industrial Zone, Yixing District, Wuxi City, Jiangsu Province, China.

Bosheng is the specialized manufacturer of various steel poles and steel components including street lighting poles, electric power poles, traffic signal poles, flag poles, wind power poles and microwave communication towers, etc.

Through Shanghai Port, which is one of the largest ports in China, we export poles to South America, Middle East, Africa, Australia, Philippines and other countries.

FAQ: 1 - Port of Loading: Shanghai, China 2 - Price term: EXW, FOB, CFR AND CIF.

3 - MOQ: 1 set 4 - Payment Term: 30%TT in deposit, 70%TT before shipment.

Or LC.

5 - Delivery: Based on your quantity.

Normally within 15 working days after receiving your deposit.
