Custmised Diameter 1 2 Inch Galvanized Pipe Octagon Steel Tubing Gb11345 Grade Welding Standard - China

Low Voltage Hot Dip Galvanized Octagonal Steel Pole, Metal Pole Specification - - - -

Material | High-quality steel Q235/SS400 | Welding Technique | Automatic submerged arc welding, AWS D1.1 | Surface Treatment | Hot dip galvanizing ASTM 123 | Welding Standard | GB11345 Grade | Thickness of Zinc Coating | 86um | Adhesive Force of Zinc Coating | GB2694-88 | Anti-wind Capacity | 36.9m/s | Anti-corrosion Lifetime | 20 years | Coating Layer | Thickness | 100um | Adhesive force | GB9286-880 | Hardness | 2H | Steel Pole Height Options | 3.5m~15m | Street Lighting Poles Type Options | Conical, polygonal Octagonal | - - - - Description 1 - We can supply the product based on client's required drawing, but also can supply the design for any kinds of electric poles for customers to select.

2 - Matercial : hot rolled coil from Q235 to Q460, ASTM573 GR65, GR50, SS400, SS490, ST52-3 3 - Deal: Hot dip galvanized Following ASTM A 123 or any other stardand by client required.

4 - Packing: Plastic bulble, Mat &Straw Bale or following client required 5 - Length : within 14meters once forming( single section) 6 - Thickness: from 2.5mm to 22mm 7 - Shape: polygonal(6-side, 8side, 12-side, 16side) round tapered.

8 - Easy install and maintenance.

Others Standard poles25FT, 30FT, 35FT, 40FT, 45FT - - - - Height (ft) | Thickness (mm) | Butt Diameter (mm) | Tip Diameter (mm) | Design Load (kg) | Yield Stress (MPA) | Zinc Coating (microns) | 25 | 2.5 | 152 | 120 | 300 | 345 | 86 | 30 | 3.0 | 226 | 127 | 500 | 345 | 86 | 35 | 3.0 | 248 | 127 | 500 | 345 | 86 | 40 | 3.0 | 317 | 127 | 500 | 345 | 86 | 45 | 3.0 | 328 | 127 | 500 | 345 | 86 | - - - - Material Test: 1 - All of our material are purchased from famous mill factory to assure the quality.

2 - A mill certificate issued by the mill factory with stamp and signature must be provided before unload the material in our factory; 3 - Before put into production, all the material must pass the chemical and physical analysis to make sure that they have met the requested strength and component.

Production Process # Raw material test # Cutting # Bending # Welding (longitudinal ) # Dimension verify # Flange welding # Hole drilling # Calibration # Deburr # Galvanization or powder coating or Bituminous painting # Recalibration # Packages - - - - Best Service: --At Jiangsu BoshengSteel Poles Co., Ltd, we alwaysproviding our clients with great quality products and superior Customer service.

| Quick Lead Time--We inform our cistomers the exact delivery time when they plac the order and then strictly following on when we agreed.

| Unbeatable Prices-- We continuously strive to find ways of reducing our production costs, and saving the cost.

| Unbeatable Quality --we always supply good quality also leading products to all of our customers.

| Brand Awareness -- The goal of any strong brand is achieve a level of awareness that instills the idea of quality and value into all of your customers.

| Special Offers.

-- In order to maintain our competitive edge, we are constantly running special offers onour products, consumer goods, and design services.

Contact our sales team to see how we can help you save a lot of money.

| Special support-- we have a policy term to support our VIP customers for products also payment.

| - - - - Terms and Conditions 1 - Price Term: EXW, FOB, CFR or CIF.

EXW: Poles Cost FOB : Pole Cost + Land Transportation + Fee on Port CFR : Pole Cost + Land Transportation + Fee on Port + Sea Freight C I F : Pole Cost + Land Transportation + Fee on Port + Sea Freight + Insurance.

2 - MOQ: One 40FT Container.

3 - Payment Term: Typically 30% by T/T as deposit, balance by T/T or L/C at sight before shipment.

Other payment way can be negotiated.

4 - Delivery Time: 15 working days per container after PI / drawing / prepayment confirmed.

5 - Package: Normally wrapped by plastic bags or burlap cloth at the top and bottom, or according to clients requirement.

Company Introduce: Through the efforts of the company staff, the support and cooperation from all over the world.

The company's products have been exported to Philippines, Malaysia, Australia, America, Africa, Latin America, Panama, Suriname, Costa Rica, Colombia, Jordan, Nigeria, etc.

We have good export experience and with 1 container export to World in average every day.

Company Contact:

• Posted By: Jiangsu Bosheng Steel Poles Co.,limited

• Phone: 86-510-80326616

• Address: Heqiao Industrial Zone, Yixing City, Jiangsu Province. China., Yixing , Jiangsu , China

• Email:

• Website: https://www.metalutilitypole.com

• Business Description: Jiangsu Bosheng Steel Poles Co., Ltd founded in 2007, Which is the specialized manufacturer of various steel poles including street lighting pole, electric power pole, traffic signal pole, flag pole, wind power pole and microwave communication tower, etc.
