Dual Polarization Mimo 4g Lte Panel Antenna 9dbi High Gain Indoor Outdoor External - China

ELECTRICAL

Model DT-PA698-2700-9-2B

Frequency Range 698-960/1710--2700MHz

Gain 8/9*2dBi

Beamwidth H: 79±5°, E: 68±5°

VSWR ≤1.8

Polarization Vertical and Horizontal or ±45°

F/B Ratio ≥13dB

Isolation ≥25dB

Max Power 100W

Nominal Impedance 50Ω

Lightning Protection DC Ground

MECHANICAL

Connector N Female*2 or customized

Antenna Dimension 280*180*60mm

Weight 0.75kg

Radome Material Waterproof ABS

Working Temperature -40℃~﹢65℃

Antenna Color White

Rated Wind Velocity 60m/s

Pole Diameter Φ35-55mm

Rated Wind Velocity 210 km/h
