Transmission Line Electrical Power Pole Hdg Polygonal Shape 132 Kv - China

HDG Polygonal Shape Electrical Power Steel Pole for 132 KV Transmission Line Specification - - - -

Steel | Yield Strength(MPa) | standard | Standard Title | Metallic element | Content | | main ingredient Q345 | 345 for Thickness<=16 | GB/T 1591-2008 (ASTM A572/A572M-15, EN10025 S355N) | High strength low alloy structural steels | C | 0.20 | | Mn | 1.70 | | Si | 0.50 | | Accessories Q235 | 235 | GB/T 700-2006 (ASTM A283 Gr.

B, EN10025 S235JR) | Carbon structural steels | | P | 0.035 | | S | 0.035 | | - - - - - - - -

Welding | Standard | Standard Title | Pole shafts&multi-sided tubular Cross arms&all accessories | AWS D1.1/D1.1M: 2010 | Structural Welding Code-Steel | Welding wire | AWS D1.1/D1.1M: 2010 | Structural Welding Code-Steel | - - - - - - - -

Hot dip galvanizing | Standard | Steel thickness/mm | Mean coating thickness/m | Metallic element | Content | Pole shafts, cross arms&bolted on accessories | ASTM A123/A123M-15 AS/NZS 4680 | >6 | 85 | Mn | 0.25%-0.40% | <3-6 | 70 | 1.5-3 | 55 | Cu | <0.15% | <1.5 | 55 | Bolts, nuts&washers | GB/T 5267.3-2008 (ISO 10684-2004) | | 54 | P | <0.025% | Foundation bolts | ASTM A153/A153M-09 | | 54 | S | <0.03% | - - - - Description: The HDG Electrical Power Steel Pole was design as customer's request.

For 132 KV transmission Line use.

And with Base Plate use Anchor Bolts to Install.

Sections with 2 and use flange to connect each segments.

The hot dip galvanized in accordance with ASTM 123 and the zinc coating at least 86 microns.

Accessories: 1 - Pole 2 - Base Plate 3 - Pole Top Cap 4 - Butt Strip Plate 5 - Holes 6 - CrossArm 7 - Grounding Nut & Bolts 8 - Anchor Bolts 9 - Climbing Rungs 10 - Identification Plate 11 - Bituminous Painting if needed 12 - Hot dip galvanized.

Through the efforts of the company staff, the support and cooperation from all over the world.

The company's products have been exported to Philippines, Malaysia, Australia, America, Africa, Latin America, Panama, Suriname, Costa Rica, Colombia, Jordan, Nigeria, etc.

We have good export experience and with 1 container export to World in average every day.

Terms and Conditions 1 - Price Term: EXW, FOB, CFR or CIF.

EXW: Poles Cost FOB : Pole Cost + Land Transportation + Fee on Port CFR : Pole Cost + Land Transportation + Fee on Port + Sea Freight C I F : Pole Cost + Land Transportation + Fee on Port + Sea Freight + Insurance.

2 - MOQ: One 40FT Container.

3 - Payment Term: Typically 30% by T/T as deposit, balance by T/T or L/C at sight before shipment.

Other payment way can be negotiated.

4 - Delivery Time: 15 working days per container after PI / drawing / prepayment confirmed.

5 - Package: Normally wrapped by plastic bags or burlap cloth at the top and bottom, or according to clients requirement.
