Walk In Stability Temperature And Humidity Chamber For Mobile Phone - China

Walk in stability temperature and humidity chamber for mobile phone 1 - Usages: Walk in climate chamber could used to test the application and the adaptability of the electronic products, assembles and materials under the low temperature, constant temperature andtemperature cyclic change conditions.

It adopts the most reasonable structure and the most stable control method, make the appearance outstanding, the operation easily.

With high security and control accuracy, it is an ideal equipment to do low temperature, constant temperature and temperature cyclic change test.

2 - Corresponding standard: GB11158 high temperature test technical conditions GB10589 low temperature test technical conditions GB10592-89 high and low temperature test technical conditions GB/T2423.1-2001 low temperature test chamber method GB/T2423.2-2001 high temperature test chamber method GB/T2423.22-2001 temperature change test method IEC60068-2-1.1990 low temperature test chamber method IEC60068-2-2.1974 high temperature test chamber method CNS: 3627, 3385, 4159, 7669, 8886; JIS: D0201, H8502, H8610, K5400, Z2371; ISO: 3768, 3769, 3770; ASTM: 8117, B268 - 3 - Main Technical Parameters - - - - Model | KMHW-4(walk-in room) | Volume(m) | 13CBM | Interior Dimensions | W 3100 H 2100 D 2000 mm | Exterior Dimensions | W 4200 H 2400 D 2200 mm | Safety Devices(standard) | No fuse breaker, over pressure, over heat and over current protection for compressor, over temperature protection, over load protection for blower, dry heat protection | Standard accessories | Sight window*1, cable port ( port50mm ) *1, chamber lamp*1, status indicator | Control System | Balanced Temperature & Humidity Control System | Refrigeration system | Water Cooled | Semi-hermetic compressor, single stage or cascade refrigeration system, | CFC free refrigerant ( HFC-507 and HFC-23 ) | Controller | Panel | 7-inch LCD Touch panel, Chinese or English display selectable | Operation model | Program or fix point running | Memory capacity | 120 programs, 1200steps, all repeat 999 cycles, part repeat 99 cycles | Accuracy | Temp: 0.1% of F.

S 1 digit Humidity: 0.1% of F.

S 1 digit | Input | Temp: pt-100, Humidity: pt-100 or 5V DCV | Comm.

port | RS-232 or RS-485 ( Softawre is option) | Temp.

range | Maximum: 80 C, 120 C; Minimum: -60 C, -50 C, -40 C, -30 C, -20 C, -10 C, 0 C | Humidity Range | 10%, 20%, 30% ~ 95% | Temp.

constancy | 0.5 C | Humidity constancy | 2.5%R.

H | Temp.

uniformity | 2.0 C | Humidity uniformity | 5.0%R.

H | Ambient Temp.

| +5 C+35 C | Wiring method | AC 380 10% 50Hz, 3 phase 4 wires + Ground Wires | Heat up time | +20 C+80 C, Within 60 min | Pull down time | +20 C ~ -55, -40 C, -20 C, -10 C, Within 120 or 90 or 60 min | Interior material | Stainless Steel Plate(SUS 304) | Exterior material | Baked Painting Steel Or Stainless steel ( SUS304) | Insulation material | Rigid polyurethane foam | Door size (mm) | Single wing: W800 x H1800; Double wing: W1600 x H1800; | Note: 1 - We reserve the right to change specifications without prior notice 2 - Customized sizes and configurations available | - - - - 4 - Features: 1 - Double walled Construction with regular and GMP models.

2 - Pre-engineered, Pre-fabricated modular panels with 80mm thickPUF' insulation with easy-to-assemble panels on site 3 - Inside coating of floor is of either aluminum or stainless steel sheet 10 SWG thick, pressed, non-slip.

4 - Perfect insulation and minimum power consumption.

5 - Fastenings are cam locks for easy assembly and possible disassembly.

6 - The door has two pane toughened glass viewing windows.

5 - The brand of the accessories: 6 - Walk-in Room Internal Show 7 - Related products:
