T2000 Printer Handheld Printer Handheld Printer manufacturer Print CTL: “Standard” means 300dpi, “Quality” means 600dpi, “Bold” means bold the font.

6 - Printing direction adjustment

“L->R”means printing from left to right.

“R->L” means printing from right to left.

7 - Delay setting

Adjusting the print delay interval, the smaller the value the shorter the delay.

8 - Time setting

Click “Set Time” button, can reset the time of system.

9 - Language setting

Language includes EN/S CN/ T CN/ Czech.

(Updating the language)

10 - Manage information

Click “manage” button, you can store different content information templates.

You can switch to your content at any time.

“New” means you can set up a new template, typing the information you want to print.

It will save automatically.

“copy” means copy a same template

“Rename” means rename the template.

“DEL” means delete the file.

“Select” means select your file.

11.

“ADD” button

Select your file, includes text, QR code, BAR code, Picture, Time, and count.

12.

“TEXT” button

Click “TEXT”button, you can add Chinese, English, number and date

The font of text:

Enter the text font, there are three vector fonts and three kinds of Bitmap fonts.

Bitmap fonts is adjustable.

Vector font effects are as follows:

Character size adjustment:

The first sliding bar, to adjust the size of the current text.

Or directly input a value, range: 20 to 180

Setting of bitmap fonts:

Click “Vector font” switch to “Bitmap font”.

The second sliding bar, to adjust the size of the current text.

Or directly input a value, range: 5p, 7p, 11p, 16p, 24p, 32p.

Small point, middle point, big point.

For Chinese, it can only print with 11p and 16p.

Character spacing adjustment:

Third slide bar, can adjust the spacing between each character.

13 - QR code setting

Click “QR”, you can input website, number, text, etc.

NOTE: if you need to input the code of wechat and website link, you need to input with “picture”.

14 - BAR code setting

Click “BAR”, then input the number.

You can choose five type of bar code.

Including Code128, code39, EAN8/13, UPCA, ITF(2of5)

15 - Picture setting

Steps are as follows, 1) The biggest size is 800px*150px(px means pixel).

You need to set the size of the picture firstly.

2) Use windows system- accessories- paint, Save as type will be “Monochrome Bitmap(*.

bmp, *.

dib)”.

3) Then input the picture to U- disk.

U disk connected to the handheld printer, then Click “Pic” to choose your file from the u disk.

16 - Time setting

Click “Time” button, it will print the current time.

17 - Calculate setting

Click “CNT”.

Calculator: counter, serial number, record number of prints, click on parameter settings, 1-8-bit variable sequence number, end value up to 99999999.

18 - Printing operation

Turn on the power switch, after the system starts, press the print button on the handle.

Blue light means printing.

You should press the button while printing.

There will be a “Di” prompt tone during printing and after printing.

Note: The main menu of the printer recently has been upgraded, will be some difference between the specification and operation.

But the actual function don’t have any change, we will have subsequent updating in the future.

time Handheld Printer Attention:

1) At the beginning of interval printing(non-continuous), the first word might be blurred.

Due to the fast drying ink, all of the handheld printer meets the same problems.

2)Add “Prejet” function.

Choose “No move” in the prejet.

Then you can press the print button before printing.

It will quickly clean the nozzle.

If you want a deeper color, please choose “quality” or “bold”.
