Medium Pressure Boiler Alloy Steel Seamless Tubesp22 Hot Rolled Cold Drawn - China

Medium Pressure Boiler Alloy Steel Seamless Tubes P22 Hot Rolled / Cold Drawn XOOS offers a comprehensive range of ASTM A335/ASME SA335 P22 high pressure steel pipe for the right technical solution, with wall thickness from Sch 10 to 140mm & OD up to 56, delivered in hold rolled or cold drawn condition depending on different sizes.

1 - Standards: ASTM A335 Standard Specification for Seamless Ferritic Alloy-Steel Pipe for High-Temperature Service 2 - Application: For high pressure boiler and steam header pipes; petrochemical industry pipes; thermal power plant; nuclear power plant; USC boiler.

3 - Ordering Information Quantity (feet, meters, or number of lengths), Name of material (seamless alloy steel pipe), Grade (P22), Manufacture (hot-finished or cold-drawn), Size using one of the following: NPS and schedule number; Outside diameter and nominal wall thickness; Outsider diameter and minimum wall thickness; Inside diameter and nominal wall thickness; Inside Diameter and minimum wall thickness.

Length (specific or random) End finish (plain end or bevel end) 4 - Chemical Requirements - - - - Chemical Requirements | Grade | UNS Designation | Composition, % | C | Mn | P max | S max | Si | Cr | Mo | Others | P22 | K21590 | 0.05-0.15 | 0.30-0.60 | 0.025 | 0.025 | 0.50 max | 1.90-2.60 | 0.87-1.13 | .

| - - - - 5 - Available Size Range - - - - OD | Thickness | mm | inch | mm | SCH | 21.3~1422 | 1/2''~ 56'' | 2.11~140 | SCH10 | *If the steel grades and size you are looking for are not listed above, please contact us for further information.

| - - - - 6 - Tensile Requirements Tensile Strength min: 60ksi / 415MPa Yield Strength min: 30ks / 205MPa 7 - Inspection & Test Chemical composition, mechanical properties ( tensile strength, yield strength, elongation, flaring, flattening, bending, hardness, impact test), surface and dimension, NDE, hydrostatic test.

8 - Manufacture Hot Rolled or Cold Drawn 9 - Manufacturing Process Raw Material Inspection Cold Centering Heating Piercing & Rolling SIzing Heat Treatment Testing Finishing NDE Visual & Dimension Inspection Marking Storing & Shipping 10 - Supplementary Requirements - - - - S1 - Product Analysis | S2 - Transverse Tension Tests | S3 - Flattening Test | S4 - Metal Structure and Etching Tests | S5 - Photomicrographs | S6 - Photomicrographs for Individual Pieces | - - - -
