Power Plants Seamless Steel Pipemedium Pressure Random Fixed Length - China

Power Plants Seamless Steel Pipe Medium Pressure Random / Fixed Length XOOS is providing high pressure P11 seamless pipes, mostly used in power plants.

The products are supplied with 3.1 certificates, according to EN 10204 - Certification according to 3.2 can be agreed at the time of order.

1 - Application: For the low and medium pressure boiler and steam header pipes; For the high-pressure boiler and steam pipes, and the petrochemical industry pipes; Power plant; Chemical Fertilizer; Petrochemicals; Offshore Oils; Gas Productions; Refineries and etc.

2 - Standards: ASTM A335 Standard Specification for Seamless Ferritic Alloy-Steel Pipe for High-Temperature Service 3 - Ordering Information Quantity (feet, meters, or number of lengths), Name of material (seamless alloy steel pipe), Grade (P11), Manufacture (hot-finished or cold-drawn), Size using one of the following: NPS and schedule number; Outside diameter and nominal wall thickness; Outsider diameter and minimum wall thickness; Inside diameter and nominal wall thickness; Inside Diameter and minimum wall thickness.

Length (specific or random) End finish (plain end or bevel end) 4 - Chemical Requirements - - - - Chemical Requirements | Grade | UNS Designation | Composition, % | C | Mn | P max | S max | Si | Cr | Mo | Others | P11 | K11597 | 0.05-0.15 | 0.30-0.60 | 0.025 | 0.025 | 0.50-1.00 | 1.00-1.50 | 0.44-0.65 | .

| - - - - 5 - Available Size Range - - - - OD | Thickness | mm | inch | mm | SCH | 21.3~1422 | 1/2''~ 56'' | 2.11~140 | SCH10 | *If the steel grades and size you are looking for are not listed above, please contact us for further information.

| - - - - 6 - Tensile Requirements Tensile Strength min: 60ksi / 415MPa Yield Strength min: 30ks / 205MPa 7 - Inspection & Test Chemical composition, mechanical properties ( tensile strength, yield strength, elongation, flaring, flattening, bending, hardness, impact test), surface and dimension, NDE, hydrostatic test.

8 - Manufacture Hot Rolled or Cold Drawn 9 - Manufacturing Process Raw Material Inspection Cold Centering Heating Piercing & Rolling SIzing Heat Treatment Testing Finishing NDE Visual & Dimension Inspection Marking Storing & Shipping 10 - Supplementary Requirements - - - - S1 - Product Analysis | S2 - Transverse Tension Tests | S3 - Flattening Test | S4 - Metal Structure and Etching Tests | S5 - Photomicrographs | S6 - Photomicrographs for Individual Pieces | - - - -
