Seamless Alloy Steel Astm A335 P92 Pipe For High Pressure Boiler - China

Seamless Alloy Steel ASTM A335 P92 Pipe for High Pressure Boiler ASTM A335 P92 is the part of ASTM A335 - The pipe shall be suitable for bending, flanging, and similar forming operations, and for fusion welding.

The steel material shall conform to chemical composition, tensile property, and hardness requirements.

1 - Ordering Information Quantity (feet, meters, or number of lengths), Name of material (seamless alloy steel pipe), Grade (P92), Manufacture (hot-finished or cold-drawn), Size using one of the following: NPS and schedule number; Outside diameter and nominal wall thickness; Outsider diameter and minimum wall thickness; Inside diameter and nominal wall thickness; Inside Diameter and minimum wall thickness.

Length (specific or random) End finish (plain end or bevel end) 2 - Standards: ASTM A335 Standard Specification for Seamless Ferritic Alloy-Steel Pipe for High-Temperature Service 3 - Application: For high pressure boiler and steam header pipes; petrochemical industry pipes; thermal power plant; nuclear power plant; USC boiler.

4 - Chemical Requirements - - - - Chemical Requirements | Grade | UNS Designation | Composition, % | C | Mn | P max | S max | Si | Cr | Mo | Others | P92 | K92460 | 0.07-0.13 | 0.30-0.60 | 0.020 | 0.010 | 0.50 max | 8.50-9.50 | 0.30-0.60 | V 0.15-0.25 | N 0.03-0.07 | Ni 0.40 max | Al 0.02 max | Cb 0.04-0.09 | W 1.5-2.00 | B 0.001-0.006 | Ti 0.01 max | Zr 0.01 max | - - - - 5 - Available Size Range - - - - OD | Thickness | mm | inch | mm | SCH | 21.3~1422 | 1/2''~ 56'' | 2.11~140 | SCH10 | *If the steel grades and size you are looking for are not listed above, please contact us for further information.

| - - - - 6 - Tensile Requirements Tensile Strength min: 90ksi620MPa Yield Strength min: 64ksi/440MPa 7 - Inspection & Test Chemical composition, mechanical properties ( tensile strength, yield strength, elongation, flaring, flattening, bending, hardness, impact test), surface and dimension, NDE, hydrostatic test.

8 - Manufacture Hot Rolled or Cold Drawn 9 - Manufacturing Process Raw Material Inspection Cold Centering Heating Piercing & Rolling SIzing Heat Treatment Testing Finishing NDE Visual & Dimension Inspection Marking Storing & Shipping 10 - Supplementary Requirements - - - - S1 - Product Analysis | S2 - Transverse Tension Tests | S3 - Flattening Test | S4 - Metal Structure and Etching Tests | S5 - Photomicrographs | S6 - Photomicrographs for Individual Pieces | - - - -
