Lead Free Pvc Jacket Insulated Copper Wire 95 Percent Coverage Braid Shield - China

price: check with company for price

Lead Free Pvc Jacket Insulated Copper Wire 95 Percent Coverage Braid Shield

Products Photos Catalog Pvc Jacket Insulated Photos Catalog

UL 2464 double PVC insulation wire with Tinned or bare copper conductor and braid shield with lead free PVC jacket Construction: Rated temperature: 80 Rated voltage: 300v Reference standard: UL subject 758, UL1581 & CSA C22.2 Stranded, bare or tinned copper conductor Color-coded PVC, SRPVC, PE, XLPE, FEP, ETFE, PFA Cores cabled under aluminum mylar shield, Tinned or bare copper stranded drain wire Tinned or bare copper wire braid shield up to 95% coverage Lead free PVC jacket, Passes UL VW-1 & CSA FT1 vertical flame test Specification: - - - - Conductor | Insulation | Shield | Drain wire | Braid | Jacket | AWG | Construction (NO.

/mm) | cores | Construction (NO.

/mm) | Construction (NO.

/mm) | Construction (NO.

/mm) | Thickness (mm) | Nom.

Dia (Mm) | 28 7/0.127 | 2C | Al-mylar | 7/0.16 | 16/4/0.10 | 0.76 | 3.70 | 3C | Al-mylar | 7/0.16 | 16/4/0.10 | 0.76 | 3.70 | 4C | Al-mylar | 7/0.16 | 16/4/0.10 | 0.76 | 4.10 | 5C | Al-mylar | 7/0.16 | 16/4/0.10 | 0.76 | 4.30 | 6C | Al-mylar | 7/0.16 | 16/5/0.10 | 0.76 | 4.30 | 7C | Al-mylar | 7/0.16 | 16/5/0.10 | 0.76 | 4.30 | 8C | Al-mylar | 7/0.16 | 16/5/0.10 | 0.76 | 4.60 | 9C | Al-mylar | 7/0.16 | 16/5/0.10 | 0.76 | 4.90 | 10C | Al-mylar | 7/0.16 | 16/5/0.10 | 0.76 | 5.10 | 26 7/0.16 | 2C | Al-mylar | 7/0.20 | 16/4/0.10 | 0.76 | 4.00 | 3C | Al-mylar | 7/0.20 | 16/4/0.10 | 0.76 | 4.00 | 4C | Al-mylar | 7/0.20 | 16/4/0.10 | 0.76 | 4.30 | 5C | Al-mylar | 7/0.20 | 16/4/0.10 | 0.76 | 4.60 | 6C | Al-mylar | 7/0.20 | 16/5/0.10 | 0.76 | 4.90 | 7C | Al-mylar | 7/0.20 | 16/5/0.10 | 0.76 | 5.10 | 8C | Al-mylar | 7/0.20 | 16/5/0.10 | 0.76 | 5.30 | 9C | Al-mylar | 7/0.20 | 16/5/0.10 | 0.76 | 5.50 | 10C | Al-mylar | 7/0.20 | 16/5/0.10 | 0.76 | 5.70 | - - - -


Company Contact:


  • Phone: 86-0769-85235539

  • Address: No.3 Jiedong Road Humen Town Dongguan City, Guangdong Province, China, Dongguan , Guangdong , China

  • Email: Email


Published date: January 9, 2018

  • Business Description: Founded in 2004, Fort offers a highly alternative to your current cable supplier, with quality, services, capacity and innovation.

    As a manufacturer with offices and factory in Dongguan, the heart of the manufacturing industry in China, Fort electronics is facing to the worldwide.
