Electrical Switch Box Bender Machine - China
price: 80000.00 Dollar US$
New design galvanized steel electric meter box production solution & meter box roll forming machine production line.
Equipment for producting galvanized steel /stainless steel meter box Electric Box production line technical parameters No.
ITEM PARAMETER REMARK
1 MATERIAL Type Cold-rolled strip steel, galvanized sheet T.
(mm) 0.8-1.5mm Yield Strength (Mpa) Q235 2 Forming product Width Customized 3 Forming speed (m/min) 6-13m Including hole
4 Forming main power (KW) 7.5 KW FYR
5 Hydraulic power (KW) 18.5 KW FYR
6 Bending power (KW) 3 KW FYR
7 Voltage AC380V, 50Hz, 3P Electric meter box production line process (A) Uncoiler →Straightening→servo feeder→Hydraulic press breach device → Guide device → roll forming machine → hydraulic punch → Bending enclosure (optional)→shear device (including knife)→ finished product rack
