Enamel Coated Bolted Steel Liquid Tank For Fuel Oil Petroleum Storage Tanks - China

Glass-Fused-to-Steel (GFS), also known as Glass-Lined-Steel (GLS) and Liquid Storage Tanks, these names all means the same thing.

that the tank panels are fused inside and out with a glass enamel that binds to the metal providing many advantages over standard epoxy coated or welded painted storage tanks.

How is the production process of Glass-Fused-to-Steel? Firstly preparing well all of the Ti-rich steel as drawing, and then cutting holes and corners as per drawing on our laser cutting machine ( CNC cutting machine ), after all of the steel sheet be cut, which need to get rid of the burs on the surface, and then rolling job begins after all of the steel sheet is qualified, then we will spray the steel sheet and burn it in the oven with 800-950 degree last few minutes until the enamel is dry on the surface .

When all of the finish of the job which not means the job is done, do some inspection on the surface the qualified one will send to the warehouse and pack.

We pack it according to international export standard, EPE will be used on each steel sheet tied a few sheets together and put them into a wooden frame to avoid scratches during shipment.

Bolted Steel Liquid Storage Tank Specifications Coating color dark blue, dark green, white, and customized

A standard steel plate size effective size 2400mm x 1200 m

Steel plates thickness 3mm - 12mm, depends on the diameter & height

Coating thickness 0.25mm - 0.4mm, two coating internal and external

Acid and alkalinity proof standard coating suits for PH3 - PH11, special coating suits for PH1 - PH14

Adhesion 3, 450N/cm

Elastic same as steel sheet, around 500KN/mm

Hardness 6.0 Mohs

Service life >30 years

Spark test >1500 V

Permeability gas and liquid impermeable

Easy yo clean smooth, glossy, inert, anti-adhesion

Corrosion resistance excellent ! Suitable for waste water salt water, sea water, high sulfur crude oil, salt fox, organic and inorganic compounds Bolted Steel Liquid Storage Tank Manufacturer Center Enamel Co., Ltd is not only the first Glass-Fused-to-Steel Tanks manufacturer and supplier in China, but also the most experienced Glass-Fused-to-Steel tanks manufacturer in all of Asia.

Center Enamel Glass-Fused-to-Steel tanks engineering & design, product testing and quality system are in strict accordance with AWWA D103-09, OSHA, ISO/EN 28765, NSF61 and NFPA etc.

international standards.

CEC Glass-Fused-to-Steel tanks are widely used in drinking/potable water, industrial effluents, municipal sewage, bio-energy, landfill leachate, agriculture etc.

applications.

Until 2018, Center Enamel Glass-Fused-to-Steel tanks have been exported to more than 60 countries including the USA, Australia, Canada, Malaysia, Indonesia, Russia, UAE, Panama, India and South Africa etc.

The superior product quality and prompt service gain us worldwide recognition.
