Nsf 61 Bolted Steel Tanks For Storing Emergency Water Supply - China

Our bolted steel tanks is NSF approved.

The tank's steel round (cylindrical) shell is made of two layers of enamel plates coated on both sides.

These flakes are attached with special superior bolts and sealed with elastic silicone (sealant).

The surface of the connecting material and the shell itself are well treated.

Bolted steel has been recognized as an excellent water and wastewater treatment tank Bolted steel tanks are used in a wide range of commercial and industrial applications, from water and chemical storage to food applications and dry bulk storage silos.

Standard capacity ranges from 20 cubic meters to 20, 000 cubic meters.

Center Enamel's Glass-Fused-to-Steel tanks engineering design meet or exceed AWWA D103-09 and EN/ISO28765: 2011, and our GFS tank engineers make tank engineering calculation on each specific tank structure according to project local environmental conditions, such as snow load, wind speed, seismic zone etc., to make sure the tank structure's adequate security in long-term service life.

Bolted Steel Tanks Specifications Coating color dark blue, dark green, white, and customized

A standard steel plate size effective size 2400mm x 1200 m

Steel plates thickness 3mm - 12mm, depends on the diameter & height

Coating thickness 0.25mm - 0.4mm, two coatings internal and external

Acid and alkalinity proof standard coating suits for PH3 - PH11, special coating suits for PH1 - PH14

Adhesion 3, 450N/cm

Elastic same as steel sheet, around 500KN/mm

Hardness 6.0 Mohs

Service life >30 years

Spark test >1500 V

Permeability gas and liquid impermeable

Easy yo clean smooth, glossy, inert, anti-adhesion

Corrosion resistance excellent! Suitable for wastewater salt water, seawater, high sulfur crude oil, salt fox, organic and inorganic compounds The bolt tank is fused by glass into steel and is produced and completed on site, greatly reducing the time and labor involved on site.

Once delivered, each section is installed, sealed with a gasket and bolted to the adjacent section.

This makes the installation process fast and easy, much faster than that of concrete or welded canisters, and unaffected by weather delays that tend to hinder the installation of competitive designs.

Comparison of various tanks No Item Cement tank Carbon steel tank Enamel tank

1 Construction time >90 day > 60 days <15 days

2 Process technology demand strict Welding difficult easy

3 Installation technology demand Strict & complicated difficult Convenient & easy

4 removal impossible difficult easy

5 appearance normal normal good Center Enamel Co., Ltd is not only the first Glass-Fused-to-Steel Tanks manufacturer and supplier in China, but also the most experienced Glass-Fused-to-Steel tanks manufacturer in all of Asia.

Center Enamel Glass-Fused-to-Steel tanks engineering & design, product testing and quality system are in strict accordance with AWWA D103-09, OSHA, ISO/EN 28765, NSF61, API and NFPA etc.

international standards.

CEC Glass-Fused-to-Steel tanks are widely used in drinking/potable water, industrial effluents, municipal sewage, bio-energy, landfill leachate, agriculture etc.

applications.

Until 2018, Center Enamel Glass-Fused-to-Steel tanks have been exported to more than 60 countries including USA, Australia, Canada, Malaysia, Indonesia, Russia, UAE, Panama, India and South Africa etc.

The superior product quality and prompt service gain us worldwide recognition.
