Glass Fused Steel Potable Water Storage Tanks Easy To Be Installed - China

Our glass fused to steel potable water storage tanks are also called glass fused to steel tank (GFS tanks), The glass fused to steel sheet is made of special steel ART310 containing rich titanium that makes the steel sheet twice the strength than ordinary steel plate.

Inside and outside the steel plate coated with two layers of enamel, after drying, heat the steel in 900 ℃ high temperature, makes the steel sheet to achieve the best performance of both: the strength and flexibility of the steel combined with the corrosion resistance of the glass.

Glass-Fused-to-Steel technology is the premium coating technology in the storage tanks market, and Glass-Fused-to-Steel tanks are widely used in bio-energy, municipal sewage, landfill leachate, and industrial wastewater treatment, etc.

Bolted Steel Water Storage Tanks Easy To be installed Without the Effect Weather Easy To be installed Without the Effect Weather

They are constructed from individual steel panels that are manufactured and finished at an enclosed facility, then transported to the site and bolted together using the appropriate gaskets and fasteners for the product that will be stored.

Unlike conventional concrete or welded storage solutions, which require extensive fabrication and finishing processes onsite, bolted tanks offer quick installation, lower shipping costs, and they can be assembled in nearly any type of weather, eliminating many weather-related delays.

Glass Fused to Steel Potable Water Storage Tanks Specifications Coating color dark blue, dark green, white, and customized

A standard steel plate size effective size 2400mm x 1200 m

Steel plates thickness 3mm - 12mm, depends on the diameter & height

Coating thickness 0.25mm - 0.4mm, two coatings internal and external

Acid and alkalinity proof standard coating suits for PH3 - PH11, special coating suits for PH1 - PH14

Adhesion 3, 450N/cm

Elastic same as steel sheet, around 500KN/mm

Hardness 6.0 Mohs

Service life >30 years

Spark test >1500 V

Permeability gas and liquid impermeable

Easy yo clean smooth, glossy, inert, anti-adhesion

Corrosion resistance excellent! Suitable for wastewater salt water, seawater, high sulfur crude oil, salt fox, organic and inorganic compounds About Us Center Enamel Co., Ltd is not only the first Glass-Fused-to-Steel Tanks manufacturer and supplier in China but also the most experienced Glass-Fused-to-Steel tanks manufacturer in all of Asia.

Center Enamel Glass-Fused-to-Steel tanks engineering & design, product testing and quality system are in strict accordance with AWWA D103-09, OSHA, ISO/EN 28765, NSF61, API, and NFPA, etc.

international standards.

CEC Glass-Fused-to-Steel tanks are widely used in drinking/potable water, industrial effluents, municipal sewage, bio-energy, landfill leachate, agriculture etc.

applications.

Until 2018, Center Enamel Glass-Fused-to-Steel tanks have been exported to more than 45 countries including USA, Australia, Canada, Malaysia, Indonesia, Russia, UAE, Panama, India, and South Africa, etc.

The superior product quality and prompt service gain us worldwide recognition.
