Glass Fused To Steel Waste Water Storage Tanks Iso9001 Chemical Resistance - China

Center Enamel has been specialized in glass fused to steel wastewater storage tanks for many years.

We employed advanced technology to make durable glass fused to steel tanks, which are manufactured through an enameling process of the steel.

In the enameling furnace, the powder-coated steel sheets are heated up to approx.

860 degrees Celsius.

At this temperature the enamel powder melts, thus forming a corrosion-resistant fusion with the surface of the metal.

The pH is with a range of 1-14 - With the corrosion resistance of the glass application, the waste/gas is not in contact with the steel.

The porcelain enamel coating added to the steel tank interior is the plumbing industry’s time-tested and trusted system for tank protection.

So it has been recognized as an ideal solution for wastewater treatment plants.

Our glass fused to steel tanks are ISO9001: 2008 certified.

We strive to make a breakthrough in global tank market in the near future.

Glass Fused to Steel Waste Water Storage Tanks Specifications Coating color dark blue, dark green, white, and customized

A standard steel plate size effective size 2400mm x 1200 m

Steel plates thickness 3mm - 12mm, depends on the diameter & height

Coating thickness 0.25mm - 0.4mm, two coatings internal and external

Acid and alkalinity proof standard coating suits for PH3 - PH11, special coating suits for PH1 - PH14

Adhesion 3, 450N/cm

Elastic same as steel sheet, around 500KN/mm

Hardness 6.0 Mohs

Service life >30 years

Spark test >1500 V

Permeability gas and liquid impermeable

Easy yo clean smooth, glossy, inert, anti-adhesion

Corrosion resistance excellent! Suitable for wastewater salt water, seawater, high sulfur crude oil, salt fox, organic and inorganic compounds Glass Fused to Steel Waste Water Storage Tanks Advantages Short construction period, cost-effective tank solution Superior corrosion resistance, service life is more than 30 years Easy to install, no need for big installation equipment and/or very skilled labors Tank volume can be easily expanded It can be dismantled, removed and relocated Elegant appearance, tank color can be customized About Center Enamel Center Enamel Co., Ltd is not only the first Glass-Fused-to-Steel Tanks manufacturer and supplier in China, but also the most experienced Glass-Fused-to-Steel tanks manufacturer in all of Asia.

Center Enamel Glass-Fused-to-Steel tanks engineering & design, product testing and quality system are in strict accordance with AWWA D103-09, OSHA, ISO/EN 28765, NSF61 and NFPA etc.

international standards.

CEC Glass-Fused-to-Steel tanks are widely used in drinking/potable water, industrial effluents, municipal sewage, bio-energy, landfill leachate, agriculture etc.

applications.

Until 2018, Center Enamel Glass-Fused-to-Steel tanks have been exported to more than 60 countries including USA, Australia, Canada, Malaysia, Indonesia, Russia, UAE, Panama, India and South Africa etc.

The superior product quality and prompt service gain us worldwide recognition.
