Glass Lined Steel Anaerobic Digester Tank For Large Biogas Plant - China

Glass Lined Steel anaerobic digestion tanks are made of glass fused to steel which is superior in corrosion resistant as it is actually the combination of “ glass ” and “ steel “ .

So it has the advantages of both: superior corrosion resistance of glass, and strength and flexibility of steel.

This is the combination of both to achieve the best.

Bolted Steel tank is the best tank to be used as an anaerobic reactor, especially when the media inside than tank could be highly corrosive.

Anaerobic Digestion is a process that decomposes and converts the organic waste into biogas gas, the biological process is called anaerobic digester.

The digester reaction needs to do it in some conditions, the decomposition needs to accomplish in the absence of oxygen environment, airtightness environment will be selected as a reactor.

In order to achieve full reaction agitator and heating system are required, there is also some temperature requirements during the reaction, mesophiles are most efficient at moderate temperature ranges between 25°C - 40°C while thermophiles run most efficiently at higher ranges between 45°C - 80° C.

Glass Lined Steel Anaerobic Digestion Tanks Specifications Coating color dark blue, dark green, white, and customized

A standard steel plate size effective size 2400mm x 1200 m

Steel plates thickness 3mm - 12mm, depends on the diameter & height

Coating thickness 0.25mm - 0.4mm, two coating internal and external

Acid and alkalinity proof standard coating suits for PH3 - PH11, special coating suits for PH1 - PH14

Adhesion 3, 450N/cm

Elastic same as steel sheet, around 500KN/mm

Hardness 6.0 Mohs

Service life >30 years

Spark test >1500 V

Permeability gas and liquid impermeable

Easy yo clean smooth, glossy, inert, anti-adhesion

Corrosion resistance excellent ! Suitable for waste water salt water, sea water, high sulfur crude oil, salt fox, organic and inorganic compounds Glass Lined Steel Anaerobic Digestion Tanks Manufacturer Center Enamel Co., Ltd is not only the first Glass-Fused-to-Steel Tanks manufacturer and supplier in China but also the most experienced Glass-Fused-to-Steel tanks manufacturer in all of Asia.

Center Enamel Glass-Fused-to-Steel tanks engineering & design, product testing and quality system are in strict accordance with AWWA D103-09, OSHA, ISO/EN 28765, NSF61 and NFPA etc.

international standards.

CEC Glass-Fused-to-Steel tanks are widely used in drinking/potable water, industrial effluents, municipal sewage, bio-energy, landfill leachate, agriculture etc.

applications.

Until 2018, Center Enamel Glass-Fused-to-Steel tanks have been exported to more than 60 countries including USA, Australia, Canada, Malaysia, Indonesia, Russia, UAE, Panama, India and South Africa etc.

The superior product quality and prompt service gain us worldwide recognition.
