Brass Dn15 Rotary Piston Water Meter Multi Jet Plastic Housing Sanitary - China

Rotary piston type, Multi Jet Water Meter, plastic meter housing for sanitary water meter DN15 ProductDescription This type of water meter, also called volumetric type water meter, which can be used for a remote reading transmission system as equipped with a built-in sensor.

Applications range: These water meter are for record the total water volumetric flow meter in cubic, liter which pass through the closed pipe line, like water utilities, municipal water supply, etc.

Key Features # Volumetric rotary piston principle of measurement; # LXHY-1520 is no location limitation for installation.

# Accuracy is not to be affected wherever installed at a horizontal, vertical or inclined pipeline; # Register is sealed with a special liquid to keep a clear reading in long term service; # Mechanism use of high-quality material to ensure a stable characteristic; # Accurate measurement with conformity to ISO 4064 class C.

Note: Technical data conform to International Standard ISO 4064 - Application: Measuring the volume of cold portable water passing through the pipeline.

Data sheet - - - - Model | Size | Class | Q4 | Q3 | Q2 | Q1 | Min read | Max read | m/h | | m/h | m/h | LXHY-15 | 15mm | C | 3 | 1.5 | 22.5 | 15 | 0.0001 | 9999 | LXHY-20 | 20mm | C | 5 | 2.5 | 37.5 | 25 | 0.0001 | 9999 | LXHY-25 | 25mm | C | 7.875 | 6.3 | 63 | 39.4 | 0.0001 | 9999 | - - - - Flow curve Pressure curve Competitive Advantage: # Compliance to international standards: ISO4064 / GBT778 / Q/320700JR05-2003 # Strict process control # Advanced calibration equipment # Engineer team Production line Meter box

Company Contact:

• Posted By: Shanghai I Fluid Technology Co., Ltd.

• Phone: 86-21-67627650

• Address: Room 811-Building 143, No. 1399 Husong Road, Shanghai, China, Shanghai , Shanghai , China

• Email:

• Website: https://www.industrial-watermeter.com

• Business Description: Shanghai I Fluid Technology Co., Ltd, a technique based company.

  We focus on the deployment , installation and management system of smart metering and smart grid in all utility sectors, include but not limited to water, heat, gas and electricity.
