Cnc Vertical Lathe - China
price: 55900.00 Dollar US$
Quick Details
Condition:
New
Type:
VERTICAL
Max.
Length of Workpiece (mm):
1600
Max.
Spindle Speed (r.p.m):
62 r.p.m
Machining Capacity:
Heavy Duty
Spindle Bore(mm):
None
Width of bed (mm):
0 mm
Spindle Motor Power(kW):
55
No.
of Spindles:
Single
Number of Axes:
2
Travel (X Axis)(mm):
2500 mm
Travel (Z Axis)(mm):
1600 mm
Place of Origin:
Liaoning, China
Brand Name:
Haisen
Model Number:
CK5225
Certification:
CE ISO
Tool Post Stations:
4
Weight (KG):
35000
Warranty:
1 Year
After-sales Service Provided:
Online support, Video technical support, Free spare parts, Field installation, commissioning and training, Field maintenance and repair service
After Warranty Service:
No service
Applicable Industries:
Machinery Repair Shops, Manufacturing Plant, Construction works, Energy & Mining
Key Selling Points:
Competitive Price
Local Service Location:
None
Showroom Location:
None
Marketing Type:
New Product 2020
Machinery Test Report:
Provided
Video outgoing-inspection:
Provided
Warranty of core components:
1 Year
Core Components:
Bearing, Motor, Pump, Gear, PLC, Pressure vessel, Engine, Gearbox
Max height of work piece:
1600 mm
Max weight of work piece:
10 t
Workbench diameter:
2250 mm
Workbench speed range:
2-62 r/min
Max torque of Worktable:
60 KN.
M
Max cutting force of tool post:
40 KN
Size of tool shank section:
30*40 mm
Square ram size:
240*240 mm
Beam travel:
1400 mm
Beam movement speed:
350 mm/min
Company Contact:
- Posted By: Iso
- Phone: +8613324038181
- Address: No.9-1 Haifu Road, Dalian Free Trade Zone, Liaoning Province, China., Dalian , Liaoning , China
- Email:
- Website: http://www.hs-machinetools.com/
Published date: July 13, 2021
- Business Description: Dalian Haisen Machinery Co.,Ltd. is the accredited machine producing company in China.
Providing unparalleled quality with sheer excellence.
Haisen specialized in machine field and continually improving to develop high quality, high speed, high precision technology machine tools.
Fully equipped facility can provide high level different machine tools for pipeline, valves, military, automotive, a erospace, locomotive, energy, shipping and other industries.
Our machine types are: vertical machining center, swiss lathe, vertical lathe machine, Pipe Thread Lathe and CNC Lathe Machine.
