Etherwan El100t Photoelectric Converter - China

price: 17000.00 Dollar US$

Etherwan El100t Photoelectric Converter

Products Photos Catalog Etherwan El100t Photos Catalog

ETHERWAN EL100T Photoelectric converter Overview The EL100 Series provide media conversion between 10/100BASE-T(X) and 100BASE-FX Fiber.

Easy plug-andplay design facilitates network infrastructure construction.

Through DIP switch selection, Link-Fault-Pass-Through (LFPT) function can be active or disabled.

User can choose between store-and-forward mode and converter mode through DIP switch selection.

The EL100 series is designed for SC or ST fiber connection applications.

The commercial grade media converter supports EtherWAN EMC1600 chassis system for easy group installation.

The EL100 is the ideal media converter for enterprise environments.

Highlights Fiber Media Converter: Supports multi-mode and single mode fiber with SC or ST connector options DIP Switch Configurable: Store-and-forward mode or converter mode selectable (default: store-and-forward mode) Link-fault-pass-through enable or disable Full-duplex or half-duplex of Ethernet port enable or disable Full-duplex or half-duplex of fiber port enable or disable Link-Fault-Pass-Through (LFPT): LFPT function lets network operators be aware of network connection status If a link fails, the LFPT function will notify the connected device and disable the connection Specifications Interface Ethernet Port 10/100BASE-TX: 1 port 100BASE-FX: 1 port LED Indicators Per Unit: Power Per Port: 10/100TX: Link/Activity, Full duplex/Collision, Speed Per Port 100FX: Link/Activity, Full duplex/Collision Environmental Operating Temp: 0 to 45°C (32 to 113°F) Storage Temp: -10 to 70°C (-14 to 158°F) Relative Humidity: 5% to 95% (non-condensing) Regulatory ISO: Manufactured in ISO-9001 facility Safety: UL 62368-1 Emission Compliance: CE Mark Class A FCC Part 15B Class A VCCI Class A Power Input 12VDC Power Consumption 1.92W max.

0.16A@12VDC Physical Casing Material Aluminum Dimensions 80.3 x 109.2 x 23.8mm (W x D x H) 3.16" x 4.30" x 0.94" Weight 0.15kg (0.33lbs) Installation Type Wall mounting, or in EMC1600 Chassis System


Company Contact:

  • Posted By: ZH

  • Phone: 15305925923

  • Address: Jimei North Road, Jimei District, China, XiaMen , China

  • Email: Email


Published date: July 29, 2024

  • Business Description: We are located in the beautiful Fujian Province of China, with professional products and services and adequate inventory.

    Specializing in shipbuilding, chemical, petroleum, storage, natural gas, steel, subway and a series of chemical core equipment products.
