Bd 1500 Sheathed Wire Stripping And Transverse Terminal Crimping Machine - China

Characteristic

1 - wire stripping and crimping terminal are completed at one time, waste skin is blown away by inhalation to ensure that the pressing depth is 100% the same.

2 - It adopts mechanical cam control, precision reducer and motor as power source.

All transmission parts have been hardened, which greatly increases the strength and wear resistance of the parts.

Actions are accurate and easy to operate.

Stripping length, stripping depth, mechanical adjustment, simple debugging, more accurate.

Silent model.

No clutch, frequency converter to control the machine operation, working noise is low.

3 - Applicable wire: AV, AVS, AVSS, CAVUS, KV, KIV, UL, IV, Teflon, fibre, etc.

Model: BD-1500

Power Supply: AC220V 50/ 60HZ

Size: L500*W340* H620mm

Weight: 75KG

Power: 550W

Productivity: 4500pcs/h

Pressure capacity: 1.5T

Air Source: 0.3~0.6mpa

Applicable wire Diameter: AWG30#-AWG18#(ac cording to wire)

Applicable wire: AV, AVS, AVSS, CAVUS, KV, KIV, UL, IV, Teflon, fibre, etc.

Stripping length: 0.5mm-10.0mm

Tangent error: 0.05mm-0.1mm

Position error: 0.05mm-0.1mm

Company Contact:

• Posted By: Wenzhou Zhaozhuang Automation Equipment Co., Ltd.

• Phone: +86-0577-88935088

• Address: 2nd Floor, Building 1, No. 128, Juguangyuan Middle Road, Ouhai District, Wenzhou, Zhejiang, China, wenzhou , zhejiang , China

• Email:

• Business Description: Wenzhou Zhaozhuang Automation Equipment Co., Ltd. specializes in the production of enameled wire stripping-free piercing terminal, motor copper-clad aluminum, copper, aluminum enameled wire end and power lead-out welding new scheme, using the paint-free piercing terminal crimping process, Five processes, such as lacquering, winding, dip flux, immersion tin, trimming head, etc., can be energized with one pressure, saving money and labor, making the environmental protection of production process and production products reach the international advanced level and improving Production efficiency.

  The workers' stripping machine, tin furnace and tin dust equipment are all in the province.

  As the country becomes more and more strict with environmental protection, this process directly subverts the soldering process.

  The products are used in motors and motors, air conditioner motors, exhaust motors, capacitor motors.

  , range hood motor, DC brushless motor, small AC and DC motor, water pump, air compressor, washing machine, generator, transformer, power tools, etc.

  Our company has developed the latest enamelled wire stripping-free piercing terminal, which does not require stripping and soldering, so that the process of enameled wire and aluminum enameled wire is more environmentally friendly and simple.

  Reduce production, reduce production processes and labor, and greatly improve production efficiency.

  This product can be used to change the welding or riveting process of the original stripping of copper and aluminum enameled wires.

  It can realize one-time crimping and conduction, and the electrical performance is stable.

  Compared with the original process, it saves time and labor.

  Environmentally friendly, non-polluting, and more stable performance, fully meet the ROHS directive requirements.

  Currently, the product is widely used by many manufacturers of electrical and mechanical equipment and related enameled wire connection products.

  The piercing terminal is adapted to connect the double-stranded or multi-strand enameled wire in parallel with the power lead-out wire, and the production and operation of the terminal block and the copper and aluminum paint stripping terminal (anti-oxidation, good electrical performance).

  In addition, our company specializes in producing automatic scraping machine, computer stripping machine, peeling and ending machine, automatic peeling and ending machine, cable tie tightening machine, servo terminal machine, fully automatic eight-head dip tinning machine, off Wire harness processing equipment such as paint machine and various terminal connectors, welcome new and old customers to inquire.
