Double Layer 2 Ply Corrugated Cardboard Production Line - China

Double layer /2 ply corrugated cardboard production line

Corrugated cardboard production line

Double layer /2 ply corrugated flute line

Electrical Mill Roll Stand

With the expansion of business scope, Shandong RiNo International Trade Co., Ltd quickly moves forward to the world and becomes an export-oriented company that integrates production and trade, includes paper packaging products, corrugated packaging machinery equipment, packaging product manufacturing equipment & consumables such as Corrugated Cardboard Machine, Printing Machine, Folder Gluer Machine, Automatic Die-cutting machine, Iron Wire and many other products, providing a full range of services from product to technical support.

Features

1 - Electrical shaftless mill roll stand, which is used in corrugated cardboard production line, its function is supporting the paper mill roll.

2 - Symmetrical structure can install two rolls of paper at the same time and continually change paper.

3 - Paper roll clamp-loosen, life-lower, movement, contraposition, translation operated by electric driven.

4 - Max.

diameter: 1600mm

5 - Range of width: 1200mm-1800mm

6 - Pneumatic or manual control web tension

Single Facer corrugated rewinding machine

Features

1 - Design Speed: 100m/min.

2 - Effective width: 1200mm-2500mm

3 - The diameter of corrugated roller: 280mm.

4 - Type of corrugated roller A/B/C/D/E/F/G

5 - Cardboard transmit adopts vacuum suction method, with wind control system.

Keep flute profiles stable of the lower-roller in the condition of running up.

6 - The upper-lower corrugated roller are made of high quality 48CrMo alloy steel and heat-treatment.

The rigidity is HRC58-60 degree, the surface are grinded.

7 - Upper and lower corrugated roller are unit assemblage, the whole corrugated rollers group can be move and quick replacement, to change flute type quickly.

8 - Drive decelerate box adopts oil immersed type lubricating to reduce noise.

Keep running stable.

9 - Single face lift-lower of upper corrugated roller, pressure roller and gluer roller are controlled by pneumatic control.

10 - Glue parts adopt auto supply glue circularly.

11 - The glue part surface are treated by special mesh snicked and chrome plated.

12 - Glue part can be running independently or non-independently while stopped.

Adopt main motor frequency conversion control.

13 - Bearing of corrugated rollers, and pressure roller adopt high-temperature lubricate grease to keep running smoothly and durably.
