Xc 03018 Wire Stripping Machine - China

1 - Use: XC-03018-enameled wire paint scraper.

It is a compact, easy-to-use and hand-held tool.

This machine takes foreign technology.

It can adjust the length of paint stripping, and applies a variety of enameled wire, can quickly and clean remove the paint.

Completely replaces the traditional manual working, eg: sandpaper scraping, liquid medicine corrosion.

It not only greatly improves the efficiency, but also strong welding.

It is a idea equipment for coil industry and maintenance like electrical equipment, electronics, instrumentation, transformers, household appliances, Coil electric tools, and so on.

It combined with adjuster, motor and paint scraper, taking the foot pedal switch.

It is efficient convenient novel stable.

2 - Properties and parameters: 1, wire diameter: Φ0.3-1.5 mm 2, voltage: ~ 220V 25W 3, mode of operation: table type, foot pedal

4, paint scraping length: 3-50mm 5, the speed of adjustment: steppes speed regulation 3 - Operation way: 1, put the wire at the Turret central, press the power switch, the motor rotation immediately.

2, push the wire slowly and it can be removed.

3, release the power button switches, motor immediately stop rotating.

4 - Related note: 1, when there are different specifications, please adjusting the speed, if the diameter is small please turn the speed to the small fig, the large diameter to the big fig.

when the paint can not be completely removed, accelerate speed until it can clean the paint completely.

If the wire is injured when scraping you should turn down speed until meet the requirements so far.

According to the method select the most appropriate speed, as the diameter of the corresponding speed, can be considered to have adjusted well.

2, scraping paint to the end of the location of enameled wire; do not let the wire’s end leave the blade immediately, it is necessary to stop such as knives from the knife-edge after the rotation, so as to avoid the injuring of the wire.

3, before do the scraping work please straight the wire.

4, after using the machine, you can take off the security cover to clean powder.

Company Contact:

• Posted By: Wenzhou Zhaozhuang Automation Equipment Co., Ltd.

• Phone: +86-0577-88935088

• Address: 2nd Floor, Building 1, No. 128, Juguangyuan Middle Road, Ouhai District, Wenzhou, Zhejiang, China, wenzhou , zhejiang , China

• Email:

• Business Description: Wenzhou Zhaozhuang Automation Equipment Co., Ltd. specializes in the production of enameled wire stripping-free piercing terminal, motor copper-clad aluminum, copper, aluminum enameled wire end and power lead-out welding new scheme, using the paint-free piercing terminal crimping process, Five processes, such as lacquering, winding, dip flux, immersion tin, trimming head, etc., can be energized with one pressure, saving money and labor, making the environmental protection of production process and production products reach the international advanced level and improving Production efficiency.

  The workers' stripping machine, tin furnace and tin dust equipment are all in the province.

  As the country becomes more and more strict with environmental protection, this process directly subverts the soldering process.

  The products are used in motors and motors, air conditioner motors, exhaust motors, capacitor motors.

  , range hood motor, DC brushless motor, small AC and DC motor, water pump, air compressor, washing machine, generator, transformer, power tools, etc.

  Our company has developed the latest enamelled wire stripping-free piercing terminal, which does not require stripping and soldering, so that the process of enameled wire and aluminum enameled wire is more environmentally friendly and simple.

  Reduce production, reduce production processes and labor, and greatly improve production efficiency.

  This product can be used to change the welding or riveting process of the original stripping of copper and aluminum enameled wires.

  It can realize one-time crimping and conduction, and the electrical performance is stable.

  Compared with the original process, it saves time and labor.

  Environmentally friendly, non-polluting, and more stable performance, fully meet the ROHS directive requirements.

  Currently, the product is widely used by many manufacturers of electrical and mechanical equipment and related enameled wire connection products.

  The piercing terminal is adapted to connect the double-stranded or multi-strand enameled wire in parallel with the power lead-out wire, and the production and operation of the terminal block and the copper and aluminum paint stripping terminal (anti-oxidation, good electrical performance).

  In addition, our company specializes in producing automatic scraping machine, computer stripping machine, peeling and ending machine, automatic peeling and ending machine, cable tie tightening machine, servo terminal machine, fully automatic eight-head dip tinning machine, off Wire harness processing equipment such as paint machine and various terminal connectors, welcome new and old customers to inquire.
