Single Double Drive Knitted Fabric Heat Setting Machinetwo Bowl Padder - China

Full-inverter controlled Stenter finishing machine, Easy operation & maintenance 1 - Applications: This machine is suitable for, Heat setting of fabric, Chemical Finishing on fabric, Drying of fabric (knitted or woven fabrics).

2 - Technical specifications: - - - - Machine Roller width: | 1400-3800mm | Fabric Working width: | 1200-3600mm | Heat system: | oil/gas/steam | Width adjustment range: | 700-3600mm | Chambers quantity | As required | Max.

Temperature of the chambers: | 100-220 | Fabric held by: | clip/pin/combined | Air pressure: | above 0.5mpa | Overfeed range: | -10% to 80% | Installed power: | Approx 120Kw | - - - - 3 - Process: Open width entry ---Fabric Centering device --- Two-bowl Padder Auto weft straightener--- Lower overfeeding screw expending ---Upper overfeeding --- Edge detecting --- Pinning on--- Chambers for heat setting ---Pinning off--- Air cooling --- End section --- Plaiting.

4 - Feature: 1) Overfeed equipped with motor and gearbox.

2) Chain tension pneumatic controlled.

3) Uncurler with infrared feeler.

5 - Machine advantages: 1) High quality and advanced Electrical Control system; All the electrical control components are used international famous brand, such as Siemen/Mistubishi PLC and HMI, Mistubishi inverter, E+L selvedge tracing device and uncurler, Maxon Gas Burner etc.

2) High Efficiency Heat Exchanger or Gas burner ( Maxon, USA) was equipped, which can quickly heat up the chamber temperature to the set temperature, greatly reduced the dull time and achieve production efficiency.

3) High efficient overfeeding result can be reached.
